| Server |
| Image compression |
: |
JPEG (Motion JPEG) |
| Video resolution |
: |
640 x 480, 320 x 240 (default), 160 x 120 |
| Image quality |
: |
JPEG (favor clarity, standard, favor motion) |
| Frame rate |
: |
Max. 12 frames/sec. (640 x 480); Max. 30 frames/sec. (320 x 240, 160 x 120) |
| Security |
: |
User ID/Password/IPsec |
| Supported protocols |
: |
IPv4/IPv6 dual stack. IPv4: TCP, UDP, IP, HTTP, FTP, SMTP, DHCP, DNS, ARP, ICMP, POP3, NTP, IPsec, UPnP. IPv6: TCP, UDP, IP, HTTP, FTP, SMTP, DNS, ICMPv6, POP3, NDP, NTP, IPsec |
| User access limit |
: |
Max. 30 simultaneous accesses (max. 10 accesses with voice reception) |
| Buffered images |
: |
Approx. 125 images (320 x 240) •standard image quality •with time display •without using SD Memory Card |
| Image transfer method |
: |
SMTP, FTP |
| Image buffer/transfer triggers |
: |
Alarm, timer or motion detection |
Network Camera |
| Zoom |
: |
42x zoom (21x optical, 2x digital) |
| Viewing angle |
: |
Horizontal--tele: 2.6° (optical)/1.3° (digital), wide: 51°; Vertical----tele: 1.9° (optical)/0.9° (digital), wide: 38° |
| Pan (horizontal direction) |
: |
-175° up to +175° |
| Tilt (vertical direction) |
: |
-120° up to 0° (On a table), 0° up to +90° (On a ceiling) |
| Revolving speed |
: |
Pan: Max. 300°/sec; Tilt: Max. 200°/sec |
| Sensor type |
: |
1/4 inch CCD sensor, approx. 380,000 pixels |
| Lens focal point |
: |
Auto/manual (40 steps) |
| Lens brightness |
: |
F1.6 (Wide) - 3.6 (Tele) |
| Required light intensity |
: |
3 to 100,000 lux (in color night view mode: 0.09 to 100,000 lux) |
Audio |
| Audio communication |
: |
2-Way half duplex |
| Audio compression |
: |
ADPCM 32 kbps |
| Audio bandwidth |
: |
300 Hz - 3.4 kHz |
| Audio input |
: |
External microphone input terminal |
| Audio output |
: |
Audio line output terminal for external speaker |
Wireless |
| Standards |
: |
— |
| Antenna |
: |
— |
| Number of channel |
: |
— |
| Transmission speed |
: |
— |
| Security |
: |
— |
Terminal |
| Network interface |
: |
Ethernet (10Base-T/100Base-TX) |
| External I/O connector |
: |
Input: 2, output: 1 |
| Video output |
: |
Analog composite (NTSC) |
| Audio output |
: |
3.5 mm stereo mini jack (output is mono) |
| External Microphone Input |
: |
3.5 mm mini jack |
| SD Memory Card slot |
: |
Full size (operation guaranteed for 2GB, 1GB, 512MB, 256MB, 128MB and 64MB SD Memory Cards) |
General |
| Operating temperature |
: |
0°C to +40° (+32°F to +104°F) |
| Operating humidity |
: |
20% to 80% (no condensation) |
| Dimensions (H x W x D) |
: |
140 x 123 x 123 mm (5 1/2 x 4 13/16 x 4 13/16 inches) |
| Weight (only the unit) |
: |
650 g (1.43 lb) |
| Power supply (E) |
: |
PoE: 48 V, IEEEE 802.3af-compliant Power over Ethernet |
| Power supply (CE) |
: |
PoE: 48 V, IEEEE 802.3af-compliant Power over Ethernet |
| Power supply(US) |
: |
PoE: 48 V, IEEEE 802.3af-compliant Power over Ethernet |
| Consumption |
: |
PoE: 11 W |
