Camera |
Image Sensor: |
1/3" Progressive Scan CMOS |
Signal System: |
PAL/NTSC |
Min. Illumination: |
0.01Lux @ (F1.2, AGC ON) ,0 Lux with IR |
Shutter time: |
1/25(1/30) s to 1/100,000 s |
Lens: |
4mm@ F2.0, Angle of view:75.8°
(2.8mm, 6mm, 12mm optional) |
Lens Mount: |
M12 |
Adjustment Range: |
Pan:0° - 355°, Tilt: 0° - 65° |
Day& Night: |
IR cut filter with auto switch |
Digital noise reduction: |
3D DNR |
|
Compression Standard |
Video Compression: |
H.264/M-JPEG |
Bit Rate: |
32 Kbps ~ 16 Mbps |
Dual Stream: |
Yes |
|
Image |
Max. Image Resolution: |
1280x960 |
Frame Rate: |
50 Hz: 25 fps (1280 × 960), 25 fps (1280 x 720)
60 Hz: 30 fps (1280 × 960), 30 fps (1280 x 720) |
Image Settings: |
Saturation, brightness, contrast adjustable through client software or web browser |
Backlight compensation: |
Yes, zone optional |
BLC: |
Yes, zone configurable |
|
Network |
Network Storage: |
NAS (iSCSI optional) |
Alarm Trigger: |
Motion detection, Tampering alarm |
Protocols: |
TCP/IP, HTTP, DHCP, DNS, DDNS, RTP, RTSP, PPPoE, SMTP, NTP, UPnP,
ICMP,IGMP,SNMP, FTP, 802.1X, QoS, HTTPS(SIP,SRTP,IPv6 optional) |
Security: |
User authentication, watermark |
System Compatibility: |
ONVIF, PSIA, CGI |
|
Interface |
Communication Interface: |
1 RJ45 10M / 100M ethernet interface |
|
General |
Operating Conditions: |
-30 °C ~ 60 °C (-22 °F ~ 140 °F)
Humidity 95% or less (non-condensing) |
Power Supply: |
12 VDC ± 10%, PoE (802.3af) |
Power Consumption: |
Max. 5 W (Max. 7 W with IR cut filter on) |
Impact Protection: |
IEC60068-2-75Eh, 50J; EN50102, up to IK10 |
Weather Proof: |
IP66 |
IR Range: |
Approx. 10 to 30 meters |
Dimensions: |
Φ111 × 82 (4.4” × 3.2”) |
Weight: |
500g (1.1 lbs) |
|
