| Camera |
| Image Sensor: |
1/3" Progressive Scan CMOS |
| Min. Illumination: |
0.5 lux@F1.2, AGC on, 0.1 lux@F1.2, AGC on, sens-up × 5
1.1 lux@F1.8, AGC on, 0.2 lux@F1.8, AGC on, sens-up × 5 |
| Shutter time: |
1/25s ~1/100,000s |
| Lens: |
4 mm @F1.8
Angle of view: 71° |
| Lens Mount: |
M12 |
| Day& Night: |
Electronic |
|
| Compression Standard |
| Video Compression: |
H.264 / MPEG4 / MJPEG |
| Bit Rate: |
32 Kbps ~ 16 Mbps |
| Audio Compression: |
G.711/G.726 |
| Dual Stream: |
Yes |
|
| Image |
| Max. Image Resolution: |
1600x1200 |
| Frame Rate: |
50 Hz:
12.5 fps (1600 × 1200)
12.5 fps (1600 × 912)
25 fps (1280 × 960)
25 fps (1280 × 720)
60 Hz:
15 fps (1600 × 1200)
15 fps (1600 × 912)
25 fps (1280 × 960)
30 fps (1280 × 720) |
| Image Settings: |
Saturation, brightness, contrast adjustable through client software or web browser |
|
| Network |
| Network Storage: |
NAS (iSCSI optional) |
| Alarm Trigger: |
Motion detection, tampering alarm, network disconnect , IP address conflict, storage exception |
| Protocols: |
TCP/IP, HTTP, DHCP, DNS, DDNS, RTP, RTSP, PPPoE, SMTP, NTP, SNMP, HTTPS, FTP,802.1x, Qos (SIP, SRTP, IPv6 optional) |
| Security: |
User authentication, watermark |
| System Compatibility: |
ONVIF, PSIA, CGI |
|
| Interface |
| Audio: |
Internal Microphone and Speaker |
| Communication Interface: |
1 RJ45 10M / 100M ethernet interface |
| On-board storage: |
Built-in Micro SD slot, up to 32 GB |
| Reset Button: |
Yes |
|
| General |
| Operating Conditions: |
-10 °C ~ 60 °C (14 °F ~ 140 °F)
Humidity 90% or less (non-condensing) |
| Power Supply: |
5 V DC ± 10% /PoE (802.3af) |
| Power Consumption: |
4W MAX |
| Dimensions: |
70.4 × 110 × 47.6mm
(2.77" × 4.33" × 1.87") |
| Weight: |
250g (0.55 lbs) |
|
