Image Sensor
|
1/3" Progressive Scan CMOS |
|
Slow Shutter
|
Support |
|
Lens
|
2.0mm/2.8mm/4mm optional |
|
Video Compression
|
H.264/MJPEG |
|
Video Bit Rate
|
32Kbps~16Mbps |
|
Audio Bit Rate
|
64Kbps(G.711) / 16Kbps(G.722.1) / 16Kbps(G.726) / 32-128Kbps(MP2L2) |
|
Max. Image Resolution
|
1280x960 |
|
Frame Rate
|
50Hz: 25fps(1280 × 960, 1280 × 720); 60Hz: 30fps (1280 × 960, 1280 × 720) |
|
Image settings
|
Rotate Mode, Saturation, Brightness, Contrast, Sharpness adjustable by client software or web browser |
|
Day/Night
|
Auto/Schedule/Triggered by Alarm In |
|
Alarm Triggers
|
Motion detection, Dynamic Analysis, Tampering alarm, Network disconnect, IP address conflict, Storage exception |
|
Protocol
|
TCP/IP, UDP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, Bonjour |
|
Security
|
One-key reset, flash-prevention, dual streams, heartbeat, mirror, password protection, privacy mask, Watermark, IP address filtering, Anonymous access |
|
Communication
|
1 RJ45 10M/100M Ethernet port, 1 RS-485 interface and 1 RS-232 interface |
|
On Board Storage
|
Built-in Micro SD/SDHC/SDXC card slot, up to 64 GB |
|
Weight
|
83.78×69.84×95mm |
|
Power Supply
|
12VDC ± 10% |
|
Power Consumption (±10%)
|
Max. 5 W |
