Image Sensor
|
1/3” Progressive Scan CMOS |
Min.Illumination
|
0.01 Lux @(F1.2,AGC ON), 0 Lux with IR 0.014 Lux @(F1.4,AGC ON), 0 Lux with IR |
Shutter Time
|
1/3 s to 1/100,000 s |
Lens
|
4 mm @ F2.0 (6mm, 16mm optional) Angle of view: 85° |
Lens Mount
|
M12 |
Day/Night
|
ICR |
Digital Noise Reduction
|
3D DNR |
Wide Dynamic Range
|
Digital WDR |
Video Compression Format
|
H.264 / MJPEG |
H.264 codec profile
|
BaseLine Profile / Main Profile |
Bit rate
|
32 Kbps ~ 12 Mbps |
Dual Stream
|
Yes |
Max. Resolution
|
1920 X 1080 |
Frame Rate
|
50 Hz: 25fps(1920 × 1080), 25 fps (1280 × 960), 25 fps (1280 x 720) 60 Hz: 25fps(1920 × 1080), 30 fps (1280 × 960), 30 fps (1280 x 720) |
Image settings
|
Rotate mode, Saturation, Brightness, Contrast adjustable by client software or web browser |
Backlight Compensation
|
Yes, zone optional |
ROI
|
Support |
Network storage
|
NAS |
Alarm Triggers
|
Motion detection, tampering alarm, scene change detection, face detection, intrusion detection, Line crossing detection |
Protocol
|
TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, Bonjour |
System compatibility
|
ONVIF, PSIA, CGI, ISAPI |
General functionalities
|
User Authentication, Watermark, IP address filtering, Anonymous access |
Communication interface
|
1 RJ45 10M / 100M Ethernet interface |
Operating Conditions
|
-30 °C ~ 60 °C (-22°F ~ 140 °F) humidity 95% or less (non-condensing) |
Power Supply
|
12 VDC ± 10% , PoE (802.3af ) |
Power Consumption
|
-I3: max. 5.5W -I5: max. 7W -I8: max 10W |
Ingress Protection
|
IP66 |
IR Range
|
-I3: 1pcs EXIR LED, up to 30m -I5: 2pcs EXIR LEDs, up to 50m -I8: 4pcs EXIR LEDs, up to 80m |
Dimension
|
Φ105mm×300mm |
Weight
|
1200g |
