Image Sensor
|
1/3” Progressive Scan CMOS |
|
Min.Illumination
|
0.01 Lux @(F1.2,AGC ON), 0 Lux with IR 0.014 Lux @(F1.4,AGC ON), 0 Lux with IR |
|
Shutter Time
|
1/3 s to 1/100,000 s |
|
Lens
|
4 mm @ F2.0 (6mm, 16mm optional) Angle of view: 85° |
|
Lens Mount
|
M12 |
|
Day/Night
|
3D DNR |
|
Wide Dynamic Range
|
Digital WDR |
|
Video Compression Format
|
H.264 / MJPEG |
|
H.264 codec profile
|
BaseLine Profile / Main Profile |
|
Bit rate
|
32 Kbps ~ 12 Mbps |
|
Dual Stream
|
Yes |
|
Max. Resolution
|
1920 X 1080 |
|
Image settings
|
Rotate mode, Saturation, Brightness, Contrast adjustable by client software or web browser |
|
Backlight Compensation
|
Yes, zone optional |
|
ROI
|
Support |
|
Network storage
|
NAS |
|
Alarm Triggers
|
Motion detection, tampering alarm, scene change detection, face detection, intrusion detection, Line crossing detection |
|
Protocol
|
TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, Bonjour |
|
System Specifications
|
Intel Pentium Dual-Core E2140, Asus I945G-IGA, 250GB SATA (1+3 EA), DVD-Multi (SATA), SDC-5100, 16CH, G.726, Windows XP Pro Embedded / Recovery Solution, 1 VGA (1024 x 768), 1CH SPOT (2), Multi CH SPOT(1) |
|
General functionalities
|
User Authentication, Watermark, IP address filtering, Anonymous access |
|
Communication interface
|
1 RJ45 10M / 100M Ethernet interface |
|
Operating Conditions
|
-30 °C ~ 60 °C (-22°F ~ 140 °F) humidity 95% or less (non-condensing) |
|
Power Supply
|
12 VDC ± 10% , PoE (802.3af ) |
|
Power Consumption
|
-I3: max. 5.5W -I5: max. 7W -I8: max 10W |
|
Ingress Protection
|
IP66 |
|
IR Range
|
-I3: 1pcs EXIR LED, up to 30m -I5: 2pcs EXIR LEDs, up to 50m -I8: 4pcs EXIR LEDs, up to 80m |
|
Dimension
|
Φ105mm×300mm |
|
Weight
|
1200g |
