Hikvision DS-1100KI
Hikvision DS-1100KI
Network Keyboard
Ergonomic design with 800×480 LCD touch panel
Live view and playback of video on screen at up to 1080p resolution
1-channel video decoding for local preview
Video capture and recording to local U-flash disk
Compatible with DVR/DVS, matrix, network camera/dome, PC-DVR, etc.
Support 15 operators, and each user is allowed to operate 256 devices
Hikvision DS-1100KI
Network Keyboard
Jual Hikvision DS-1100KI controller PTZ aksesoris dengan harga yang murah dan terjangkau. Controller PTZ ini memiliki Ergonomic design dengan LCD Touch Panel 800 X 480. Mempunyai kemampuan untuk Live View dan Playback dari Video di layar hingga 1080P resolusi, terdapat juga kemampuan video record dan capture yang ter-integrasi dengan USB Flash Disk. Compatible dengan DVR/DVS, Matrix, Kamera Network/Dome, PC-DVR, etc. Dilengkapi support hingga 15 operator, setiap pengguna bisa menjalankan hingga 256 Device.
Control Mode
Screen
|
Screen:
|
7” TFT LCD monitor with touch panel
|
|
Resolution:
|
800 × 480
|
Joystick
|
Joystick:
|
4-axis joystick
|
Audio Input/Output
|
Line In:
|
1-ch, 3.5 mm connector (2.0 Vp-p, 1 kΩ)
|
|
Audio Out:
|
1-ch, 3.5 mm connector (Linear, 560 Ω)
|
External Interface
|
Network Interface:
|
1 10M/100M/1000M Ethernet interface
|
|
RS-232 Interface:
|
1, RS-232 interface
|
|
RS-485 Interface:
|
1, RS-485 interface
|
|
USB Interface:
|
1, USB2.0 (for data storage and device upgrade)
|
Client GUI
|
Date & Time Display:
|
Time: Week: Date, 6 formats on the Client
|
|
Client:
|
Support iVMS-4200
|
|
Web Browser:
|
IE 7+, Chrome 18 +, Firefox 5.0 +, Safari 5.02 +
|
General
|
Power Supply:
|
12V DC
|
|
Power Consumption:
|
≤ 15W
|
|
Working Temperature:
|
-10°C ~ 55°C (14°F ~ 131°F )
|
|
Working Humidity:
|
10% ~ 90%
|
|
Dimensions (W × D × H):
|
435 × 193 × 110 mm (17.13” × 7.60” × 4.33”)
|
|
Weight:
|
2 Kg (4.41lb)
|
