Image Sensor
|
1/1.8’’ Progressive Scan CMOS |
|
Min.Illumination
|
Color: 0.001 Lux @ (F1.2, AGC ON), B/W: 0.0001 Lux @ (F1.2, AGC ON) |
|
Focal length
|
3.8-16mm/11-40mm/7-33mm optional |
|
Day/Night
|
IR Cut Filter |
|
Video Compression
|
H.264/MPEG4/MJPEG |
|
Video Bit Rate
|
32 Kbps – 16 Mbps |
|
Audio Compression
|
G.711/G.722.1/G.726/MP2L2 |
|
Audio Bit Rate
|
64Kbps(G.711) / 16Kbps(G.722.1) / 16Kbps(G.726) / 32-128Kbps(MP2L2) |
|
Max. Image Resolution
|
1920 × 1080 |
|
Frame Rate
|
50Hz: 50fps(1920 × 1080,1280 × 960, 1280 × 720) 60Hz: 60fps (1920 × 1080, 1280 × 960,1280 × 720) |
|
Third Stream
|
Independent with Main Stream and Sub Stream, up to 50Hz: 25fps(1920 × 1080); 60Hz: 30fps (1920 × 1080) |
|
Image settings
|
Rotate Mode, Saturation, Brightness, Contrast, Sharpness adjustable by client software or web browser |
|
Network storage
|
Rotate Mode, SatNAS (Support NFS,SMB/CIFS), ANRuration, Brightness, Contrast, Sharpness adjustable by client software or web browser |
|
Alarm Triggers
|
Motion detection, Tampering alarm, Network disconnect, IP address conflict, Storage exception |
|
Protocol
|
TCP/IP, UDP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP,PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, Bonjour |
|
Standard
|
ONVIF(PROFILE S,PROFILE G),PSIA,CGI,ISAPI |
|
Communication interface
|
1 RJ45 10M/100M Ethernet port, 1 RS-485 interface and 1 RS-232 interface |
|
On Board Storage
|
Built-in Micro SD/SDHC/SDXC slot, up to 128 GB |
|
Protection level
|
IP67 |
|
Power Supply
|
24 V AC ± 10%, 12 V DC ± 10%, PoE (802.3af) |
|
Power Consumption (±10%)
|
Max. 14 W (Max. 25W with white light; Max. 74W with heater) |
|
Dimensions without Stand (WxHxD)
|
445.3×110×140.6 mm |
|
Weight (approx.)
|
3800 g |
