Image Sensor
|
1/1.8" Progressive Scan CMOS |
|
Signal System
|
PAL/NTSC |
|
Min.Illumination
|
Color: 0.001 Lux @ (F1.2, AGC ON) B/W: 0.0001 Lux @ (F1.2, AGC ON) |
|
Shutter Time
|
1/1 s to 1/100,000 s |
|
Slow Shutter
|
Support |
|
Lens Mount
|
C/CS mount |
|
Day/Night
|
IR cut filter with auto switch |
|
Wide Dynamic Range
|
120 dB |
|
Video Compression Format
|
H.264/MPEG4/MJPEG |
|
Video Bit Rate
|
32Kbps~16Mbps |
|
Audio Compression
|
G.711/G.722.1/G.726/MP2L2 |
|
Max. Image Resolution
|
1920 x 1080 |
|
Frame Rate
|
50Hz:50fps(1920×1080), 50fps(1280×960), 50fps(1280×720) 60Hz:60fps(1920×1080), 60fps(1280×960), 60fps(1280×720) |
|
Third Stream
|
Independent with Main Stream and Sub Stream, up to 50Hz: 25fps (1920 × 1080) 60Hz: 30fps (1920 × 1080) |
|
Image settings
|
Rotate Mode, Saturation, Brightness, Contrast, Sharpness adjustable by client software or web browser |
|
Network storage
|
Micro SD/SDHC/SDXC card with ANR (up to 128G), NAS (Support NFS, SMB/CIFS) |
|
Alarm Triggers
|
Line crossing detection, Intrusion detection, Defocus detection, Scene change detection, Motion detection, Face detection, Dynamic analysis, Tampering alarm, Network disconnect, IP address conflict, Storage exception |
|
Protocol
|
TCP/IP,ICMP,HTTP,HTTPS,FTP,DHCP,DNS,DDNS,RTP,RTSP,RTCP, PPPoE,NTP,UPnP,SMTP,SNMP,IGMP,802.1X,QoS,IPv6,Bonjour |
|
General functionalities
|
User Authentication, Watermark, IP address filtering, anonymous access, flickerless, heartbeat, video mask |
|
System compatibility
|
ONVIF (Profile S, Profile G), PSIA, CGI, ISAPI |
|
Audio input / Two-way audio in
|
1-ch 3.5 mm audio interface, Mic in/Line in. 1 built-in Microphone |
|
Audio Output
|
1-ch 3.5mm audio interface (line level, 600 Ω) |
|
Communication interface
|
1 RJ45 10M/100M Ethernet port, 1 RS-485 interface and 1 RS-232 interface |
|
On Board Storage
|
Built-in Micro SD/SDHC/SDXC slot, up to 128 GB |
|
Power Supply
|
24VAC± 10%, 12 VDC ± 10%, PoE (802.3af) |
|
Power Consumption (±10%)
|
Max. 6 W (Max. 9W with IR cut filter on) |
|
Dimensions without Stand (WxHxD)
|
69.8×58×145 mm (2.75” × 2.28” × 5.71”) |
|
Weight (approx.)
|
830 g (1.83 lbs) |
