Produk sesudahnyaCP Plus CP-UNC-TY20FL2C

Brand: CP Plus

CP Plus CP-UNC-TY10FL5C

Rp 13.300.000

tidak termasuk pengiriman

1/3” 1.3MP Progressive scan CCD
H.264 & MJPEG dual-stream encoding
Max 12/15fps@1.3M(1280×720)&25/30fps@720P(1280x720)
D-WDR, Day/Night(ICR), 2DNR, Auto iris, AWB, AGC, BLC
8~20mm varifocal lens
Built-in 2/1 alarm in/out Max. IR LEDs length 50m
Micro SD memory, IP66
Mobile Software: CMOB
CMS Software: IPSS

Qty:

Overview
Contact Us

Specifications
Image Sensor	1/3” 1.3Megapixel PS CCD
Minimum Illumination	0. 2Lux/F1.6 (Color), 0.01Lux/F1.6(B/W), 0Lux(IR on)
Shutter Speed	Auto/Manual,1/50~1/10000s
White Balance	Auto
AGC control	Auto/Manual
Back Light Comp.	BLC / HLC / DWDR
S/N Ratio	more than 50 dB
Video Compression	H.264/MJPEG
Resolution	1.3M(1280×960) / 720P(1280×720) / D1(704×576/704×480)/ CIF(352×288)
Video Output	1 channel BNC(1.0Vp-p, 75Ω)
IR	50m
ICR	Auto(ICR) / Color / B/W
Lens	8~20mm
Privacy Masking	Up to 4 areas
Interface	RJ-45 (10/100Base-T)
Protocol	IPv4/IPv6, HTTP, HTTPS, SSL, TCP/IP, UDP, UPnP, ICMP, IGMP, SNMP, RTSP, RTP, SMTP, NTP, DHCP, DNS, PPPOE, DDNS, FTP, IP Filter, QoS, Bonjour, ONVIF Ver. 2.0
Smart Phone	iPhone, iPad, Android, Windows Phone
Operating Temperature	-10°C~+60°C, 10%~90%
Power Source	DC12V(AC24 optional)
Power Consumption	<15W
Weatherproof Standard	IP66
Dimension	118.3mm×288.3mm×101mm
Weight	2.5Kg
Micro SD	Max 32GB
User Account	10 users
Alarm IN	2 Ch.
Alarm Out	1 Ch.
Audio Input	1 channel
Audio Output	1 channel
Audio Compression	G.711a / G.711u(64kbps)/PCM(128kbps)

Namamu *

Email Anda *

Pertanyaan *

Specifications
Image Sensor	1/3” 1.3Megapixel PS CCD
Minimum Illumination	0. 2Lux/F1.6 (Color), 0.01Lux/F1.6(B/W), 0Lux(IR on)
Shutter Speed	Auto/Manual,1/50~1/10000s
White Balance	Auto
AGC control	Auto/Manual
Back Light Comp.	BLC / HLC / DWDR
S/N Ratio	more than 50 dB
Video Compression	H.264/MJPEG
Resolution	1.3M(1280×960) / 720P(1280×720) / D1(704×576/704×480)/ CIF(352×288)
Video Output	1 channel BNC(1.0Vp-p, 75Ω)
IR	50m
ICR	Auto(ICR) / Color / B/W
Lens	8~20mm
Privacy Masking	Up to 4 areas
Interface	RJ-45 (10/100Base-T)
Protocol	IPv4/IPv6, HTTP, HTTPS, SSL, TCP/IP, UDP, UPnP, ICMP, IGMP, SNMP, RTSP, RTP, SMTP, NTP, DHCP, DNS, PPPOE, DDNS, FTP, IP Filter, QoS, Bonjour, ONVIF Ver. 2.0
Smart Phone	iPhone, iPad, Android, Windows Phone
Operating Temperature	-10°C~+60°C, 10%~90%
Power Source	DC12V(AC24 optional)
Power Consumption	<15W
Weatherproof Standard	IP66
Dimension	118.3mm×288.3mm×101mm
Weight	2.5Kg
Micro SD	Max 32GB
User Account	10 users
Alarm IN	2 Ch.
Alarm Out	1 Ch.
Audio Input	1 channel
Audio Output	1 channel
Audio Compression	G.711a / G.711u(64kbps)/PCM(128kbps)

Produk-produk terkait

CP Plus CP-UAP-SC23CB

Rp 8.600.000 tidak termasuk pengiriman

1/4" High Quality Image Sensor
High Resolution of 540TVL
Min. Illumination of 0.5 Lux/F1.6
Powerful 23x Optical Zoom
Day/Night (ICR), 2D-DNR, Auto iris, Auto focus, AWB, AGC, BLC
Max 300°/s pan speed, 360° continuous pan rotation
Up to 255 presets, 5 auto scan, 8 tour, 5 pattern
Built-in 2/1 alarm I/O

CP Plus CP-UAP-SC23CL6

Rp 11.400.000 tidak termasuk pengiriman

1/4" CMOS
High Resolution of 600TVL
Min. Illumination of 0.5Lux@F1.6
Powerful 23x Optical Zoom
Day/Night (ICR), 2D-DNR, , Auto iris, Auto focus, AWB, AGC, BLC
Max 240 °/s Pan Speed, 360° Continuous Pan Rotation and Auto Flips with no Blind Spot Monitor
Up to 255 Preset, 5 Auto Scan, 8 Tour, 5 PatternAuto Recognition of General Protocols Pelco-P/D
The max. IR Distance is over 60m
OSD and Operation Prompts of Various Languages
Auto Restore to Previous PTZ and Lens Status after Power Failure
IP66 All-Environments Protection, 4000V Thunder-Proof

CP Plus CP-UAP-SC23CP

Rp 9.200.000 tidak termasuk pengiriman

1/4" High Quality Image Sensor
High Resolution of 540 TVL
Min. Illumination of 0.5 Lux/F1.6
Powerful 23x Optical ZoomDay/Night (ICR), 2D-DNR, Auto iris, Auto focus, AWB, AGC, BLCMax 300°/s pan speed, 360° continuous pan rotationUp to 255 presets, 5 auto scan, 8 tour, 5 patternBuilt-in 2/1 alarm I/OIP66

CP Plus CP-UAP-SC30CP

Rp 9.200.000 tidak termasuk pengiriman

1/4" High Quality Image Sensor
High Resolution of 540 TVL
Min. Illumination of 0.5 Lux/F1.6
Powerful 30x Optical Zoom
Day/Night (ICR), 2D-DNR, Auto iris, Auto focus, AWB, AGC, BLC
Max 300°/s pan speed, 360° continuous pan rotation
Up to 255 presets, 5 auto scan, 8 tour, 5 pattern
Built-in 2/1 alarm I/O
IP66, IK10(optional)

CP Plus CP-UAP-SY23C
