Brand: CP Plus

CP Plus CP-UNC-DY20FL2C

Rp 10.700.000

tidak termasuk pengiriman

1/3” 2Megapixel progressive scan Exmor CMOS
H.264 & MJPEG dual-stream encoding
25/30fps@1080P(1920×1080)
DWDR, Day/Night(ICR), 2DNR, Auto iris, AWB, AGC, BLC
3.3~12mm varifocal lens
IR Range of 20m
Supports PoE
Built-in 1/1 alarm in/out
Micro SD memory
Mobile Software: CMOB
CMS Software: IPSS

Qty:

Overview
Contact Us

Specifications
Image Sensor	1/3” 2Megapixel Exmor CMOS
Minimum Illumination	Color: 0. 1Lux/F1.2, B/W: 0.01Lux/F1.2
Shutter Speed	Auto/Manual 1/3~1/10000
White Balance	Auto
AGC control	Auto/Manual
Back Light Comp.	Off/BLC/HLC/DWDR
S/N Ratio	more than 50 dB
Video Compression	H.264/MJPEG
Resolution	1.3M(1280×960) / 720P(1280×720) / D1(704×576/704×480)/ CIF(352×288)
Video Output	1 channel BNC(1.0Vp-p, 75Ω)
Video Streaming	Main Stream: 1080P/720P(1 ~ 25/30fps), Sub Stream: D1/CIF(1 ~ 25/30fps)
ICR	Auto(ICR) / Color / B/W
Lens	3.3~12mm
Privacy Masking	Up to 4 areas
Interface	RJ-45 (10/100Base-T)
Protocol	IPv4/IPv6, HTTP, HTTPS, SSL, TCP/IP, UDP, UPnP, ICMP, IGMP, SNMP, RTSP, RTP, SMTP, NTP, DHCP, DNS, PPPOE, DDNS, FTP, IP Filter, QoS, Bonjour, ONVIF Ver. 2.0
Smart Phone	iPhone, iPad, Android, Windows Phone
Operating Temperature	-10°C~+60°C, 10%~90%
Power Source	DC12V, PoE(802.3af)
Power Consumption	<6W
Regulatory	CE, FCC and RoHS
Dimension	Φ140.3mm x 113.7mm
Weight	0.8kg
Micro SD	Max 32GB
User Account	10 users
Alarm IN	1 Ch.
Alarm Out	1 Ch.
Audio Input	1 channel
Audio Output	1 channel
Audio Compression	G.711a / G.711u(64kbps)/PCM(128kbps)
IR	IR Range of 20m

Namamu *

Email Anda *

Pertanyaan *

Specifications
Image Sensor	1/3” 2Megapixel Exmor CMOS
Minimum Illumination	Color: 0. 1Lux/F1.2, B/W: 0.01Lux/F1.2
Shutter Speed	Auto/Manual 1/3~1/10000
White Balance	Auto
AGC control	Auto/Manual
Back Light Comp.	Off/BLC/HLC/DWDR
S/N Ratio	more than 50 dB
Video Compression	H.264/MJPEG
Resolution	1.3M(1280×960) / 720P(1280×720) / D1(704×576/704×480)/ CIF(352×288)
Video Output	1 channel BNC(1.0Vp-p, 75Ω)
Video Streaming	Main Stream: 1080P/720P(1 ~ 25/30fps), Sub Stream: D1/CIF(1 ~ 25/30fps)
ICR	Auto(ICR) / Color / B/W
Lens	3.3~12mm
Privacy Masking	Up to 4 areas
Interface	RJ-45 (10/100Base-T)
Protocol	IPv4/IPv6, HTTP, HTTPS, SSL, TCP/IP, UDP, UPnP, ICMP, IGMP, SNMP, RTSP, RTP, SMTP, NTP, DHCP, DNS, PPPOE, DDNS, FTP, IP Filter, QoS, Bonjour, ONVIF Ver. 2.0
Smart Phone	iPhone, iPad, Android, Windows Phone
Operating Temperature	-10°C~+60°C, 10%~90%
Power Source	DC12V, PoE(802.3af)
Power Consumption	<6W
Regulatory	CE, FCC and RoHS
Dimension	Φ140.3mm x 113.7mm
Weight	0.8kg
Micro SD	Max 32GB
User Account	10 users
Alarm IN	1 Ch.
Alarm Out	1 Ch.
Audio Input	1 channel
Audio Output	1 channel
Audio Compression	G.711a / G.711u(64kbps)/PCM(128kbps)
IR	IR Range of 20m
