Image Sensor
|
1/4” progressive scan RGB CMOS |
Lens
|
Varifocal 2.8 - 10 mm, 80° - 22° view*, F1.7, fixed iris |
Light sensitivity
|
0.9 - 100000 lux, F1.7 |
Shutter Time
|
1/24500 s to 1/6 s |
Angle Adjustment
|
Pan 360°, tilt 170°, rotation 340° |
Pan/ Tilt/ Zoom
|
Digital PTZ, preset positions, guard tour |
Video Compression
|
H.264 (MPEG-4 Part 10/AVC) Motion JPEG |
Video Resolution
|
1280x800 to 160x90*1440x900 (1.3 MP) scaled resolution available via VAPIX® |
Video Framerate
|
30 fps in all resolutions |
Video Streaming
|
Multiple, individually configurable streams in H.264 and Motion JPEG Controllable frame rate and bandwidth VBR/CBR H.264 |
Image settings
|
Compression, color, brightness, sharpness, contrast, white balance, exposure control, exposure zones, backlight compensation, fine tuning of behavior at low light, mirroring of images Rotation – including Corridor Format™ Text and image overlay, privacy mask |
Security
|
Password protection, IP address filtering, HTTPS** encryption, digest authentication, user access log |
Protocol Support
|
IPv4/v6, HTTP, HTTPS**, QoS Layer 3 DiffServ, FTP, SMTP, Bonjour, UPnP, SNMPv1/v2c/v3(MIB-II), DNS, DynDNS, NTP, RTSP, RTP, TCP, UDP, IGMP, RTCP, ICMP, DHCP, ARP, SOCKS |
Application Programming Interface
|
Open API for software integration, including VAPIX® and AXIS Camera Application Platform from Axis Communications, specifications available at www.axis.com Support for AXIS Video Hosting System (AVHS) with One-Click Camera connection |
Intelligent Video
|
Video motion detection, active tampering alarm Support for AXIS Camera Application Platform enabling installation of additional applications |
Alarm Triggers
|
Intelligent video |
Alarm Events
|
File upload via FTP, HTTP and email Notification via email, HTTP and TCP |
Video Buffer
|
25 MB pre- and post alarm |
Built-in installation aids
|
Pixel counter |
Casing
|
Polycarbonate transparent cover Metal inner camera module with encapsulated electronics, 1000 kg (2200 lb.) impact-resistant metal casing |
Processor and Memory
|
ARTPEC-3, 128 MB RAM, 128 MB Flash |
Power
|
Power over Ethernet IEEE 802.3af Class 2 (max. 4.2 W) |
Connectors
|
RJ-45 10BASE-T/100BASE-TX PoE |
Operating Conditions
|
0 – 50 °C (32 – 122 °F) Humidity 20 - 80% RH (non-condensing) |
Approvals
|
EN 55022 Class B, EN 61000-3-2, EN 61000-3-3, EN 55024, FCC Part 15 Subpart B Class B, ICES-003 Class B, VCCI Class B, C-tick AS/NZS CISPR 22, EN 60950-1, KCC Class B |
Weight
|
580 g (1.3 lb.) |
Weight
|
Installation Guide, CD with installation tools, recording software and User’s Manual, key for tamper-proof screws, Windows decoder 1-user license |
