Image Sensor
|
1/4" progressive scan RGB CMOS |
Lens
|
2.8 mm, 80° viewa , F2.0 |
Light sensitivity
|
1–100000 lux, F3.0 |
Shutter Time
|
1/24500 s to 1/6 s |
Angle Adjustment
|
Pan ± 30°, Tilt 0-90°, Rotation ± 180° |
Video Compression
|
H.264 (MPEG-4 Part 10/AVC) Motion JPEG |
Video Resolution
|
1280x800b to 160x90 |
Video Streaming
|
Multiple, individually configurable streams in H.264 and Motion JPEG, Controllable frame rate and bandwidth, VBR/CBR H.264 |
Pan/ Tilt/ Zoom
|
Digital PTZ, Preset positions, Guard tour |
Image settings
|
Compression, Color, Brightness, Sharpness, Contrast, White balance, Exposure control, Exposure zones, Backlight compensation, Fine tuning of behavior at low light, Wide dynamic range – dynamic contrast, Text and image overlay, Mirroring of images, Privacy mask Rotation: 0°, 90°, 180°, 270°, including Corridor Format |
Security
|
Password protection, IP address filtering, HTTPSc encryption, IEEE 802.1Xc network access control, Digest authentication, User access log |
Protocol Support
|
IPv4/v6, HTTP, HTTPSc , SSL/TLSc , QoS Layer 3 DiffServ, FTP, CIFS/SMB, SMTP, Bonjour, UPnP™, SNMPv1/v2c/v3 (MIB-II), DNS, DynDNS, NTP, RTSP, RTP, TCP, UDP, IGMP, RTCP, ICMP, DHCP, ARP, SOCKS |
Application Programming Interface
|
Open API for software integration, including VAPIX® and AXIS Camera Application Platform; specifications at www.axis.com AXIS Video Hosting System (AVHS) with One-Click Camera Connection ONVIF Profile S, specification at www.onvif.org |
Intelligent Video
|
Video motion detection, Active tampering alarm, AXIS Camera Application Platform |
Trigger Events
|
Intelligent video |
Event actions
|
File upload: FTP, HTTP, network share and email Notification: email, HTTP and TCP Video recording to edge storage, Pre- and post-alarm video buffering, External output activation |
Data streaming
|
Event data |
Built-in installation aids
|
Pixel counter |
Casing
|
IP66-, IP67- and NEMA 4X-rated, IK08 impact-resistant aluminum and polycarbonate casing, Dehumidifying membrane, Captive screws, Not designed for mounting outside a vehicle |
Memory
|
128 MB RAM, 128 MB Flash |
Power
|
Power over Ethernet IEEE 802.3af/802.3at Type 1 Class 1, max 3.2 W |
Connectors
|
Rugged, female, D-coded M12 connector with rotatable coupling nut, All connectors support Power over Ethernet |
Edge Storage
|
Support for recording to dedicated network-attached storage (NAS) |
Operating Conditions
|
-25 °C to 50 °C (-13 °F to 122 °F) Humidity 15–100% RH (condensing) |
Approvals
|
EN 55022 Class B, EN 61000-3-2, EN 61000-3-3, EN 50121-4, EN 55024, EN 61000-6-1, EN 61000-6-2, FCC Part 15 Subpart B Class B, ICES-003 Class B, VCCI Class B, C-tick AS/NZS CISPR 22 Class B, EN 60950-1, EN 60950-22, IEC 60529 IP66/IP67, NEMA 250 Type 4X, ECE R10 rev.03 (E approval), IEC 60721-3-4 Class 4K3 (temperature range -25 °C to 50 °C), EN 50155 Class T3 (vibration, shock, bump, temperature), ISO 16750-3 (vibration), IEC 62262 Class IK08, AFNOR NF F16-101, E DIN 5510-2, UNI CEI 11170 |
Weight
|
250 g (0.55 lb) |
Included accessories
|
Lens tool, Top cover tool, Drill hole template, Mounting adapters, Installation Guide, Installation and Management Software CD, Windows decoder 1-user license |
Video Management Software
|
AXIS Camera Companion (included), AXIS Camera Station and video management software from Axis’ Application Development Partners (not included). For more information, see www.axis.com/products/video/software |
