Image Sensor
|
Progressive scan RGB CMOS 1/2.9" |
Lens
|
Varifocal, 3-10.5 mm, F1.4 Horizontal angle of view: 95°-34° Remote focus/zoom, Built-in IR-cut filter |
Day/Night
|
Automatically removable infrared-cut filter |
Shutter Time
|
1/28000 s to 2 s with power line frequency 50 Hz 1/33500 s to 2 s with power line frequency 60 Hz |
Pan/ Tilt/ Zoom
|
Digital PTZ |
Video Compression
|
H.264 Main and Baseline Profile (MPEG-4 Part 10/AVC), Motion JPEG |
Video Resolution
|
1920x1080 to 352x240 |
Video Framerate
|
25/30 fps in all resolutions with power line frequency 50/60 Hz |
Video Streaming
|
g Multiple, individually configurable streams in H.264 and Motion JPEG Controllable frame rate and bandwidth, VBR/CBR H.264 |
Image settings
|
Compression, Color, Brightness, Sharpness, Contrast, White balance, Backlight compensation, Mirroring of images, Rotation - including Corridor Format, Text and image overlay, Privacy mask Rotation: 0°, 90°, 180°, 270° Wide Dynamic Range - Dynamic Contrast, Exposure control, Exposure zones, Fine tuning of behavior at low light |
Security
|
Password protection, IP address filtering, IEEE 802.1Xa network access control, HTTPSa encryption, digest authentication, user access log |
Protocol Support
|
IPv4/v6, HTTP, HTTPSa , SSL/TLSa , QoS Layer 3 DiffServ, FTP, CIFS/SMB, SMTP, Bonjour, UPnPTM, SNMPv1/v2c/v3 (MIB-II), DNS, DynDNS, NTP, RTSP, RTP, TCP, UDP, IGMP, RTCP, ICMP, DHCP, ARP, SOCKS, SSH |
Application Programming Interface
|
Open API for software integration, including VAPIX® and AXIS Camera Application Platform, specifications available at www.axis.com AXIS Video Hosting System (AVHS) with One-Click Connection ONVIF Profile S, specification at www.onvif.org |
Analytics
|
Video motion detection, Active tampering alarm Support for AXIS Camera Application Platform enabling installation of AXIS Video Motion Detection 3, AXIS Cross Line Detection, AXIS Digital Autotracking and third-party applications, see www.axis.com/acap |
Trigger Events
|
Analytics, Edge storage events, External input, Time scheduled |
Event actions
|
File upload via FTP, HTTP and network share and email Notification via email, HTTP and TCP, Pre- and post-alarm video buffering, External output activation, Video recording to edge storage, Go to PTZ preset, Guard tour, Activation of IR illumination |
Data streaming
|
Event data |
Casing
|
Color: White NCS S 1002-B Aluminium and PC/Siloxane, 42% recycled plastic |
Memory
|
256 MB RAM, 128 MB Flash |
Power
|
Power over Ethernet IEEE 802.3af/802.3at Type 1 Class 2 Max. 6.0 W |
Connectors
|
RJ45 10BASE-T/100BASE-TX 1 alarm input and 1 output |
Edge Storage
|
Support for microSD/microSDHC/microSDXC card Support for recording to dedicated network-attached storage (NAS) For SD card and NAS recommendations see www.axis.com |
Operating Conditions
|
0 °C to 50 °C (32 °F to 122 °F) Humidity 20-80% RH (non-condensing) |
Approvals
|
EN 55022 Class B, EN 61000-6-1, EN 61000-6-2, EN 61000-3-2,EN 61000-3-3, EN 55024, FCC Part 15 Subpart B Class B, ICES-003 Class B, VCCI Class B, C-tick AS/NZS CISPR 22 Class B, KCC KN22 Class B, KN24, IEC/EN/UL 60950-1, IEC/EN 62471 EN 50581 |
Weight
|
250 g (0.55 lb) |
Included accessories
|
Stand, Installation Guide, Windows decoder 1-user license |
Optional accessories
|
Axis Mounts, Axis Housings & Cabinet, Axis Midspans, Axis Illuminators For more accessories, see www.axis.com |
Video Management Software
|
AXIS Camera Companion, AXIS Camera Station, Video management software from Axis’ Application Development Partners available on www.axis.com/techsup/software |
Language
|
German, French, Spanish, Italian, Russian, Simplified Chinese, Japanese, Korean, Portuguese |
