Brand: Axis

Axis M1144-L

Telp untuk Harga

Excellent image quality in HDTV 720p/1MP resolution
Day & Night functionality
Built-in IR LEDs
Edge storage
H.264 and Motion JPEG
Power over Ethernet
I/O support

Qty:

Overview
Specifications
Contact Us

AXIS M1144-L NETWORK CAMERA

Network Camera AXIS M1144-L, kamera CCTV yang dibuat dengan menggunakan teknologi canggih dari brand AXIS. AXIS M1144-L dengan casing yang terbuat dari material Aluminium dan PC/ABS. CCTV dengan kamera yang memiliki kualitas resolusi HDTV 720p / 1 Megapixel sehingga mampu memberikan hasil yang lebih jelas dan jernih dengan tingkat ketajaman gambar yang lebih optimal. CCTV model ini juga telah mendukung untuk media penyimpanan luar dengan menggunakan kartu SD/SDHC. Power over Ethernet yang tersemat pada kamera pengawas ini dapat menghemat biaya pemasangan atau instalasi, karena fitur PoE (Power over Ethernet) ini mampu menghantarkan listrik dengan menggunakan jaringan.

AXIS M1144-L Network kamera. Kamera CCTV dengan pengawasan yang optimal selama 24 jam, kamera CCTV model ini mampu beroperasi dengan baik pada siang dan malam hari. Teknologi PIR sensor yang ada pada AXIS M1144-L merupakan sebuah nilai lebih yang ditawarkan, karena dengan adanya PIR sensor pengawasan malam hari akan terlihat jelas. AXIS M1144-L cocok untuk mengawasi lorong ruangan, perpustakaan dan ruangan perkantoran.

FITUR AXIS M1144-L

Resolusi HDTV 720p / 1 megapiksel di frame rate penuh.
Sudah terdapat LED Inframerah.
Varifocal 2.5 - 6 mm / F1.4, DC-Iris.
Multiple H.264 streams.
Angle : 87^o - 40^o.
PoE (Power over Ethernet) IEEE 802.3af Class2.
Built-in IR LED Illumination, SD/SDHC card slot.
I/O support.

AXIS M1144-L hanya bisa Anda dapatkan hanya di JakartaCCTV dengan harga network cctv murah. Kami menyediakan paket CCTV murah dan paket DVR murah mulai dari jual IP camera, jual IR camera, jual Analog camera, jual Dome camera, jual Cube camera, jual Box camera serta jual DVR 4 channels, jual DVR 6 channels, jual DVR 8 channels, jual DVR 12 channels, jual DVR 16 channels, jual DVR 32 channels. Jual 16CH DVRmurah di Jakarta hanya di JakartaCCTV. JakartaCCTV terpercaya dan berpengalaman. Pemasangan CCTV yang langsung ditangani oleh teknisi yang berpengalaman.

Spesifikasi produk

Image Sensor	Progressive scan RGB CMOS 1/4”
Lens	Varifocal, 2.5-6 mm, F1.4 Horizontal angle of view: 87°-40°
Day/Night	Automatically removable infrared-cut filter
Min.Illumination	Color: 0.6 lux, F1.4 B/W: 0.08 lux, F1.4, 0 lux with IR illumination on
Shutter Time	1/8000 s to 1/6 s
Pan/ Tilt/ Zoom	Digital PTZ
Video Compression	H.264 Main Profile (MPEG-4 Part 10/AVC), Motion JPEG
Video Resolution	1280x800 to 352x240
Video Frame Rate	30 fps in all resolutions
Video Streaming	Multiple, individually configurable streams in H.264 and Motion JPEG Controllable frame rate and bandwidth, VBR/CBR H.264
Image settings	Compression, Color, Brightness, Sharpness, Contrast, White balance, Backlight compensation, Mirroring of images, Rotation - including Corridor Format, Text and image overlay, Privacy mask Rotation: 0°, 90°, 180°, 270°
Security	Password protection, IP address filtering, IEEE 802.1Xa network access control, HTTPSa encryption, digest authentication, user access log
Protocol Support	IPv4/v6, HTTP, HTTPSa , SSL/TLSa , QoS Layer 3 DiffServ, FTP, CIFS/SMB, SMTP, Bonjour, UPnPTM, SNMPv1/v2c/v3 (MIB-II), DNS, DynDNS, NTP, RTSP, RTP, TCP, UDP, IGMP, RTCP, ICMP, DHCP, ARP, SOCKS, SSH
Application Programming Interface	Open API for software integration, including VAPIX® and AXIS Camera Application Platform, specifications available at www.axis.com AXIS Video Hosting System (AVHS) with One-Click Connection ONVIF Profile S, specification at www.onvif.org
Analytics	Video motion detection, Active tampering alarm Support for AXIS Camera Application Platform enabling installation of AXIS Video Motion Detection 3, AXIS Cross Line Detection, AXIS Digital Autotracking and third-party applications, see www.axis.com/acap
Trigger Events	Analytics, Edge storage events, External input, Time scheduled
Event actions	File upload via FTP, HTTP and network share and email Notification via email, HTTP and TCP, Pre- and post-alarm video buffering, External output activation, Video recording to edge storage, Go to PTZ preset, Guard tour, Activation of IR illumination
Data streaming	Event data
Casing	Color: White NCS S 1002-B Aluminium and PC/ABS
Memory	256 MB RAM, 128 MB Flash
Power	Power over Ethernet IEEE 802.3af Class 2, max. 6.49 W
Connectors	RJ45 10BASE-T/100BASE-TX 1 alarm input and 1 output
Illumination LED	Optimized IR, highly efficient LEDs with adjustable intensity and angle of illumination. Range up to 15 m (50 ft).
Edge Storage	Support for microSD/microSDHC/microSDXC card Support for recording to dedicated network-attached storage (NAS) For SD card and NAS recommendations see www.axis.com
Operating Conditions	0 °C to 50 °C (32 °F to 122 °F) Humidity 20-80% RH (non-condensing)
Approvals	EN 55022 Class B, EN 61000-6-1, EN 61000-6-2, EN 61000-3-2,EN 61000-3-3, EN 55024, FCC Part 15 Subpart B Class B, ICES-003 Class B, VCCI Class B, C-tick AS/NZS CISPR 22 Class B, KCC KN22 Class B, KN24, IEC/EN/UL 60950-1, IEC/EN 62471
Weight	250 g (0.55 lb)
Included accessories	Stand, Installation Guide, Windows decoder 1-user license Lever tool
Optional accessories	Axis Mounts, Axis Housings & Cabinet, Axis Midspans, Axis Illuminators, Lenses For more accessories, see www.axis.com
Video Management Software	AXIS Camera Companion, AXIS Camera Station, Video management software from Axis’ Application Development Partners available on www.axis.com/techsup/software
Language	German, French, Spanish, Italian, Russian, Simplified Chinese, Japanese, Korean, Portuguese
