Image Sensor
|
Progressive scan RGB CMOS 1/4" |
Lens
|
Varifocal, 2.8-8 mm, F1.2 Horizontal angle of view: 77°-29° |
Min.Illumination
|
0.6 lux, F1.2 |
Shutter Time
|
1/8000 s to 1/6 s |
Video Compression
|
H.264 Baseline Profile (MPEG-4 Part 10/AVC), Motion JPEG |
Video Resolution
|
1280x800a to 160x90 |
Video Frame Rate
|
30 fps in all resolutions |
Video Streaming
|
Multiple, individually configurable streams in H.264 and Motion JPEG Controllable frame rate and bandwidth, VBR/CBR H.264 |
Pan/ Tilt/ Zoom
|
Digital PTZ |
Image settings
|
Compression, Color, Brightness, Sharpness, Contrast, White balance, Backlight compensation, Mirroring of images, Rotation - including Corridor Format, Text and image overlay, Privacy mask Rotation: 0°, 90°, 180°, 270° |
Security
|
Password protection, IP address filtering, HTTPSb encryption, IEEE 802.1Xb network access control, Digest authentication, User access log |
Protocol Support
|
IPv4/v6, HTTP, HTTPSb , SSL/TLSb , QoS Layer 3 DiffServ, FTP, CIFS/SMB, SMTP, Bonjour, UPnPTM, SNMP v1/v2c/v3 (MIB-II), DNS, DynDNS, NTP, RTSP, RTP, TCP, UDP, IGMP, RTCP, ICMP, DHCP, ARP, SOCKS, SSH |
Application Programming Interface
|
Open API for software integration, including VAPIX® and AXIS Camera Application Platform, specifications at www.axis.com AXIS Video Hosting System (AVHS) with One-Click Connection ONVIF Profile S, specification at www.onvif.org |
Analytics
|
Video motion detection, Active tampering alarm Support for AXIS Camera Application Platform enabling installation of AXIS Video Motion Detection 3, AXIS Cross Line Detection, AXIS Digital Autotracking and third-party applications, see www.axis.com/acap |
Trigger Events
|
Analytics, Edge storage events, External input, Time scheduled |
Event actions
|
File upload via FTP, HTTP and network share Email Notification via email, HTTP and TCP Pre- and post-alarm video buffering External output activation, Video recording to edge storage, Go to PTZ preset, Guard tour |
Data streaming
|
Event data |
Built-in installation aids
|
Pixel counter |
Casing
|
Color: White NCS S 1002-B Aluminum and plastic |
Memory
|
128 MB RAM, 128 MB Flash |
Power
|
Power over Ethernet IEEE 802.3af Class 1 |
Connectors
|
RJ45 10BASE-T/100BASE-TX PoE |
Edge Storage
|
Support for recording to dedicated network-attached storage (NAS) For NAS recommendations see www.axis.com |
Operating Conditions
|
-20 °C to 50 °C (-4 °F to 122 °F) Humidity 20–80% RH (non-condensing) |
Approvals
|
EN 55022 Class B, EN 61000-6-1, EN 61000-6-2, EN 61000-3-2, EN 61000-3-3, EN 55024, FCC Part 15 Subpart B Class B, ICES-003 Class B, VCCI Class B, C-tick AS/NZS CISPR 22 Class B, KCC KN22 Class B, KN24, IEC/EN/UL 60950-1 |
Weight
|
210 g (0.46 lb) |
Included accessories
|
Installation Guide, Windows decoder 1-user license Stand |
Optional accessories
|
Axis Mounts, Axis Housings & Cabinet, Axis Midspans, Axis Illuminators, Lenses For more accessories, see www.axis.com |
Video Management Software
|
AXIS Camera Companion, AXIS Camera Station, Video management software from Axis’ Application Development Partners available on www.axis.com/techsup/software |
Language
|
German, French, Spanish, Italian, Russian, Simplified Chinese, Japanese, Korean, Portuguese |
