| Camera |
| Sensor |
1/1.7", 12 megapixel, progressive scan, CMOS |
| Lens |
1.8mm@ F1.6 |
| Shutter |
Auto/Manual,shutter time:1/6 s ~1/8000 s |
| Min. Illumination |
Colour: 0.06 Lux (F1.6, AGC ON) 0 Lux with IR |
| Day/Night |
IR-cut filter with auto switch (ICR) |
| S/N |
>55dB |
| WDR |
Digital WDR |
| Video |
| Video Compression |
H.264 |
| Frame Rate |
12MP (4000*3000): Max.20fps; 4K (3008*3000): Max.25fps |
| ROI(Region of Interest) |
Supported |
| Maximum Streams |
Sextuple streams (1 fisheye view, 1 panoramic view, 4 PTZ view) |
| Evaluative Metering |
Supported |
| OSD |
Up to 8 OSDs |
| Privacy Mask |
Supported |
| Audio |
| Audio Compression |
G.711 |
| Two-way audio |
Supported |
| Storage |
| Edge Storage |
Micro SD, up to 128 GB |
| Network |
| Protocols |
L2TP, IPv4, IGMP, ICMP, ARP, TCP, UDP, DHCP, PPPoE, RTP, RTSP, DNS, DDNS, NTP, FTP, UPnP, HTTP, HTTPS, SMTP, SNMP, SIP, QoS |
| Compatible Integration |
ONVIF, API |
| Interface |
| Audio I/O |
Audio interface |
| Input: impedance 35 kΩ; amplitude 2 V [p-p] |
| Output: impedance 600 Ω; amplitude 2 V [p-p] |
| 1 built-in Microphone & 1 built-in Speaker |
| Alarm I/O |
2/ 1 |
| Multiple Alarm linkage editable |
| Serial |
1 channel RS485 interface |
| Network |
10M/100M Base-TX Auto-adaptive Ethernet |
| Video Output |
1 BNC, impedance 75 Ω; amplitude 1 V [p-p] |
| General |
| Power |
DC12V±25%, PoE(IEEE802.3at) |
| Power consumption: Max. 21 W |
| Dimensions (Ø x H) |
Φ149mm x 51.5mm (Φ5.87” x 2.03”) |
| Weight |
0.5kg(1.1lb) |
| Working Environment |
-30?~60?(-22°F ~ 140°F), Humidity ≤ 95% RH |
| Ingress Protection |
IP66 |
| Vandal Resistant |
IK10 |
