Camera |
Sensor |
1/1.9", 2megapixel, progressive scan, CMOS |
Lens |
6.5 ~ 143 mm (22x optical zoom) |
Angle of view(H) |
70° (wide) ~ 3.76° (tele) |
Shutter |
Auto/Manual; shutter time: 1/6 s ~ 1/100000 s |
Min. Illumination |
Color: 0.001 Lux (F1.5, AGC ON) 0 Lux with IR |
Iris |
Auto/Manual; F1.5 ~ F3.4 |
Day/Night |
IR-cut filter with auto switch (ICR) |
S/N |
>52dB |
WDR |
120 dB |
Video |
Max. Resolution |
1920 × 1080 |
Video Compression |
H.265,H.264,MJPEG |
Frame Rate |
1080P (1920×1080):Max.60 fps; 1080P (1920×1080):Max.15 fps;D1 (720×576):Max.8 fps
1080P (1920×1080):Max.60 fps;720P (1280×720):Max.30 fps;D1 (720×576):Max.15 fps
|
Video Streaming |
Triple |
HLC |
Supported |
Evaluative Metering |
Supported |
OSD |
Up to 8 OSDs |
Privacy Mask |
Up to 8 areas |
Digital Zoom |
Supported |
Smart |
Behavior Detection |
Intrusion, crossing line, motion detection, Auto tracking |
Exception Detection |
Audio detection |
Intelligent Identification |
Face detection |
Statistical Analysis |
People counting |
Audio |
Audio Compression |
G.711 |
Two-way audio |
Supported |
Storage |
Edge Storage |
Micro SD, up to 128 GB |
Network |
Protocols |
L2TP, IPv4, IGMP, ICMP, ARP, TCP, UDP, DHCP, PPPoE, RTP, RTSP, RTCP, DNS, DDNS, NTP, FTP, UPnP, HTTP, HTTPS, SMTP, SIP, 802.1x |
Compatible Integration |
ONVIF, API |
Pan & Tilt |
Pan Range |
360° (endless) |
Pan Speed |
0.1°/s ~ 240°/s |
Preset speed: 300°/s |
Tilt Range |
–15° ~ +90° (auto reverse) |
Tilt Speed |
0.1° ~ 160°/s |
Preset speed: 240°/s |
Number of Preset |
256 |
Patrol |
Preset patrol, route patrol, recorded patrol |
Home Position |
Supported |
Interface |
Audio I/O |
Audio cable |
Input: impedance 35 kΩ; amplitude 2 V [p-p] |
Output: impedance 600 Ω; amplitude 2 V [p-p] |
Alarm I/O |
2 / 1 |
Serial Port |
1 RS485 |
Network |
100M Base-FX SFP+10M/100M Base-TX Ethernet |
Video Output |
1 BNC, impedance 75 Ω; amplitude 1 V [p-p] |
General |
Power |
24 V AC (Default), 24 V DC |
Power consumption: 15 ~51W |
Dimensions (Ø x H) |
Ø227x359.4 mm (Ø8.9” x 14.2”) |
Weight |
5.5kg (12.1lb) |
Working Environment |
–40°C ~ +70°C (-40°F ~ 158°F), Humidity ≤ 95% RH(non-condensing) |
Ingress Protection |
IP66 |
