Camera |
Sensor |
1/1.7" CMOS, progressive scan |
Shutter |
Auto/Manual, 1/6~1/8000 s |
Min. Illumination |
Colour: 0.06 Lux (F1.2, AGC ON) B/W:0.03 Lux(F1.2, AGC ON) |
Lens Mount |
CS |
DC-Iris |
DC 4V (4 Pins) |
Motor Zoom/focus |
DC 5V (4 Pins) |
Day/Night |
Automatically removable IR-cut filter(ICR) |
S/N |
>55dB |
WDR |
Digital |
Video |
Max. Resolution |
4000 × 3000 |
Video Compression |
H.265, H.264, MJPEG |
Frame Rate |
12 MP (4000×3000):Max.20 fps; 4K (3840×2160):Max.30 fps |
Video Streaming |
Triple |
9:16 Corridor Mode |
Supported |
ROI |
Supported |
Defog |
Optical Defog & Digital Defog |
HLC |
Supported |
Evaluative Metering |
Supported |
OSD |
Up to 8 OSDs |
Privacy Mask |
Up to 4 areas |
Smart |
Behavior Detection |
Intrusion, crossing line, motion detection |
Exception Detection |
Audio detection |
Intelligent Identification |
Face detection, Defocus, Scene Change |
Statistical Analysis |
People counting |
Audio |
Audio Compression |
G.711 |
Two-way audio |
Supported |
Storage |
Edge Storage |
Micro SD, up to 128 GB |
Network |
Protocols |
IPv4, IGMP, ICMP, ARP, TCP, UDP, DHCP, PPPoE, RTP, RTSP, RTCP, DNS, DDNS, NTP, FTP, UPnP, HTTP, HTTPS, SMTP, 802.1x |
Compatible Integration |
ONVIF, API |
Interface |
Audio I/O |
3.5 mm audio interface |
Input: impedance 35 kΩ; amplitude 2 V [p-p] |
Output: impedance 600 Ω; amplitude 2 V [p-p] |
Alarm I/O |
2 / 1 |
Serial Port |
1 RS485 (support Pelco-D/P) |
Network |
100M/1000M Base-FX SFP + 100M/1000M Base-TX Ethernet |
Video Output |
1 BNC, impedance 75 Ω; amplitude 1 V [p-p] |
General |
Power |
24 V AC, 12 V DC, or PoE (IEEE802.3 af) |
Power consumption: 6.5W (9.5W with ICR on) |
Dimensions (Ø x H) |
151.5 x 71 x 65 mm (6.0“ x 2.8“ x 2.6”) (excluding the lens) |
Weight |
0.48 kg (1.1 lb) |
Working Environment |
–20°C ~ +60°C (-4°F ~ 140°F), Humidity ≤ 95% RH(non-condensing) |
