Camera |
Sensor |
1/1.9" CMOS, progressive scan |
Day/Night |
Automatically removable IR-cut filter(ICR) |
Shutter |
Auto/Manual, 1/6~1/8000 s |
Min. Illumination |
Colour: 0.002 Lux (F1.2, AGC ON) B/W:0.0002 Lux(F1.2, AGC ON) |
S/N |
>52dB |
WDR |
120 dB |
Lens Mount |
CS |
DC-Iris |
DC 4V (4 Pins) |
Motor Zoom/focus |
DC 5V (4 Pins) |
Video |
Max. Resolution |
1920 × 1080 |
Video Compression |
H.264,MJPEG |
Frame Rate |
1080P (1920×1080): Max. 60 fps; 1080P (1920×1080): Max. 15 fps;
1080P (1920×1080): Max. 60 fps; 720P (1280×720): Max. 30 fps; D1 (720×576): Max.15 fps
1080P (1920×1080): Max. 30 fps; 720P (1280×720): Max. 30 fps; D1 (720×576): Max.30 fps
|
9:16 Corridor Mode |
Supported |
ROI |
Supported |
HLC |
Supported |
Evaluative Metering |
Supported |
ABF |
Supported |
Defog |
Optical Defog & Digital Defog |
Video Streaming |
Triple |
OSD |
Up to 8 OSDs |
Privacy Mask |
Up to 4 areas |
Smart |
Behavior Detection |
Intrusion, crossing line, motion detection |
Exception Detection |
Audio detection |
Intelligent Identification |
Face detection, Defocus, Scene Change |
Statistical Analysis |
People counting |
Audio |
Audio Compression |
G.711 |
Two-way audio |
Supported |
Storage |
Edge Storage |
Micro SD, up to 128 GB |
Network |
Protocols |
IPv4, IGMP,ICMP, ARP, TCP, UDP, DHCP, PPPoE, RTP, RTSP, RTCP, DNS, DDNS, NTP, FTP, UPnP, HTTP, HTTPS, SMTP, 802.1x |
Compatible Integration |
ONVIF, API |
Interface |
Audio I/O |
3.5 mm audio interface |
Input: impedance 35 kΩ; amplitude 2 V [p-p] |
Output: impedance 600 Ω; amplitude 2 V [p-p] |
Alarm I/O |
2 / 1 |
Serial Port |
1 RS485 (support Pelco-D/P) |
Network |
100M/1000M Base-FX SFP + 100M/1000M Base-TX Ethernet |
Video Output |
1 BNC, impedance 75 Ω; amplitude 1 V [p-p] |
General |
Power |
24 V AC, 12 V DC, or PoE (IEEE802.3 af) |
Power consumption: 4.8 W (6.8W with ICR on) |
Dimensions (Ø x H) |
151.5 x 71 x 65 mm (6.0“ x 2.8“ x 2.6”) (excluding the lens) |
Weight |
0.48 kg (1.1 lb) |
Working Environment |
–20°C ~ +60°C (-4°F ~ 140°F), Humidity ≤ 95% RH(non-condensing) |
