Camera |
Sensor |
1/2.8", 2.0 megapixel, progressive scan CMOS |
Lens |
4.7 ~ 47mm@F1.6; P-Iris |
Angle of view(H) |
65°(wide) ~ 9°(tele)
|
Zoom/Focus |
10X Optical Zoom / Auto Focus |
Shutter |
Auto/Manual, 1/10~1/100,000s |
Min. Illumination |
Colour: 0.002 Lux (F1.6, AGC ON) 0Lux with IR |
IR Range |
Smart-IR ,up to 100m (328ft) IR range |
Day/Night |
IR-cut filter with auto switch (ICR) |
S/N |
>52dB |
WDR |
120dB |
Video |
Max. Resolution |
1920 × 1080 |
Video Compression |
H.265,H.264,MJPEG |
Frame Rate |
1080P (1920×1080): Max. 30 fps; 720P (1280×720): Max. 30 fps; D1 (720×576): Max. 30 fps |
Video Streaming |
Triple |
9:16 Corridor Mode |
Supported |
ROI |
Supported |
HLC |
Supported |
Evaluative Metering |
Supported |
OSD |
Up to 8 OSDs |
Privacy Mask |
Up to 8 areas |
Smart |
Behavior Detection |
Intrusion, crossing line, motion detection |
Exception Detection |
Audio detection |
Intelligent Identification |
Face detection, Defocus, Scene Change |
Statistical Analysis |
People counting |
Audio |
Audio Compression |
G.711 |
Two-way audio |
Supported |
Storage |
Edge Storage |
Micro SD, up to 128 GB |
Network |
Protocols |
L2TP, IPv4, IGMP, ICMP, ARP, TCP, UDP, DHCP, PPPoE, RTP, RTSP, RTCP, DNS, DDNS, NTP, FTP, UPnP, HTTP, HTTPS, SMTP, 802.1x |
Compatible Integration |
ONVIF, API |
Interface |
Audio I/O |
Audio cable |
Input: impedance 35 kΩ; amplitude 2 V [p-p] |
Output: impedance 600 Ω; amplitude 2 V [p-p] |
Alarm I/O |
2 / 1 |
Serial Port |
1 RS485 |
Network |
10M/100M Base-TX Ethernet |
Video Output |
1 BNC, impedance 75 Ω; amplitude 1 V [p-p] |
General |
Power |
DC12V±25%, AC24V±25% or PoE (IEEE802.3 at) |
Power consumption: 13.7W |
Dimensions (Ø x H) |
305.5 ×104.1 ×97.3mm (12.0” × 4.1” × 3.8”) |
Material |
Cast aluminum |
Weight |
1.65 kg (3.6 lb) |
Working Environment |
-40°C ~ +60°C (-40°F ~ 140°F), Humidity ≤ 95% RH(non-condensing) |
Ingress Protection |
IP67 |
