| Camera |
| Sensor |
1/1.9", 2 megapixel, progressive scan CMOS |
| Lens |
6.5 ~ 143 mm |
| Angle of view(H) |
59°(wide) ~ 3°(tele)
|
| Zoom/Focus |
22x optical zoom/ Auto Focus |
| Shutter |
Auto/Manual, 1/6~1/100000 s |
| Min. Illumination |
Colour: 0.002 Lux (F1.5, AGC ON) 0Lux with IR |
| Iris |
Auto/Manual, F1.5~F3.4, DC-Iris |
| IR Range |
up to 200 m (656 ft) IR range |
| Day/Night |
IR-cut filter with auto switch (ICR) |
| S/N |
>52dB |
| WDR |
120dB |
| Video |
| Max. Resolution |
1920 × 1080 |
| Video Compression |
H.265,H.264,MJPEG |
| Frame Rate |
1080P (1920×1080):Max.60 fps; 1080P (1920×1080):Max.15 fps
1080P (1920×1080):Max.60 fps;720P (1280×720):Max.30 fps;D1 (720×576):Max.15 fps
1080P (1920×1080):Max.30 fps;720P (1280×720):Max.30 fps;D1 (720×576):Max.30 fps
|
| Video Streaming |
Triple |
| 9:16 Corridor Mode |
Supported |
| ROI |
Supported |
| HLC |
Supported |
| Evaluative Metering |
Supported |
| OSD |
Up to 8 OSDs |
| Motion Detection |
Up to 4 areas |
| Privacy Mask |
Up to 8 areas |
| Smart |
| Behavior Detection |
Intrusion, crossing line, motion detection |
| Exception Detection |
Audio detection |
| Intelligent Identification |
Face detection, Defocus, Scene Change |
| Statistical Analysis |
People counting |
| Audio |
| Audio Compression |
G.711 |
| Two-way audio |
Supported |
| Storage |
| Edge Storage |
Micro SD, up to 128 GB |
| Network |
| Protocols |
L2TP, IPv4, IGMP, ICMP, ARP, TCP, UDP, DHCP, PPPoE, RTP, RTSP, RTCP, DNS, DDNS, NTP, FTP, UPnP, HTTP, HTTPS, SMTP, 802.1x |
| Compatible Integration |
ONVIF, API |
| Interface |
| Audio I/O |
Audio cable |
| 1 Input: impedance 35 kΩ; amplitude 2 V [p-p] |
| 1 Output: impedance 600 Ω; amplitude 2 V [p-p] |
| Alarm I/O |
2 / 1 |
| Serial Port |
1 RS485 (support Pelco-D/P) |
| Network |
100M Base-FX SFP + 100M Base-TX Ethernet |
| Video Output |
1 BNC, impedance 75 Ω; amplitude 1 V [p-p] |
| General |
| Power |
24 V AC ±25% |
| Power consumption: 6~19.5W |
| Dimensions (Ø x H) |
396.5 × 137 × 112mm (15.6” ×5.4” ×4.4”) |
| Material |
Cast aluminum |
| Weight |
3.7 kg (8.2 lb) |
| Working Environment |
-40°C ~ +60°C (-40°F ~ 140°F), Humidity ≤ 95% RH(non-condensing) |
| Ingress Protection |
IP67 |
