Video Compression
|
H.264 / MPEG4 / MJPEG |
|
Video Resolution
|
depending on the device |
|
Audio Compression Format
|
G.711 u-law (PCM), G.723, G.726 (AdPCM) |
|
Audio Functions
|
Bi-directional audio (Listen / Talk), Audio broadcasting |
|
Live Monitoring Multi-monitor
|
Up to 4 monitors (Follow the recommended system requirement) |
|
Live Monitoring Screen-split Mode
|
4 : 3 screen modes : 1, 4, 6, 8, 9, 10, 13, 16, 17, 21, 25, 36, 49, 64 16 : 9 screen modes : 6, 12, 20, 30 Full screen mode *While in multi-monitor environment, layouts and split modes for less than 100 channels will be available |
|
Live Monitoring Sequence Mode
|
Up to 16-splits |
|
Live Monitoring PTZ Control
|
Area zoom, Go to 1x zoom, PTZ sensitivity, Zoom, Patrol, swing / Autopan, Group / scan, Trace / Pattern, Preset, iris control |
|
Live Monitoring 360-degree Viewing
|
Area zoom, Go to 1x zoom, PTZ sensitivity, Zoom, Preset, PTZ / Perimeter / Quad mode (*Need to immervision enables panomorph lens) |
|
Live Monitoring Map Monitoring
|
split view mode for map layout, 2d view, Zoom in/out, video popup (instant viewer), Camera / sensor / Alarm icons on the map |
|
Live Monitoring Simple Recording
|
Recording of the selected video tile up to 1hour |
|
Live Monitoring Functions
|
Osd on/off, snapshot/prints image, Brightness/contrast control, Keep aspect ratio/original size, deinterlacing, Flip, digital zoom |
|
Search & Playback (Search)
|
Advanced search : Forensic search, video summary, Heatmap for NvR, Motion search for dvR Basic search : date/Time search, event search, POs search, Local folder search |
|
Search & Playback Split-screen Mode
|
Up to 16 cameras can be played simultaneously |
|
Search & Playback Video Control
|
Start/stop, Pause, Faster/slower forward/backward, Step forward/backward, Skip forward/backward |
|
Search & Playback Functions
|
Snapshot / Prints image |
|
Search & Playback Back up
|
Local storage, Back up format (Avi, seC) Configurable schedule for back up (*supported model only), Masking back up |
|
Event Monitoring Real-time Event List
|
shows real-time event list of the device (event status, type, device, user, time(PC)), viewing instant video image, sorting based on event priority |
|
Event Monitoring Searching Events
|
ssM : User, system device : system, Camera, sensor, Alarm out Camera : video Loss, Motion, Passing, entering, exiting, disappearing (Appearing), Tampering, Tracking, Face detection, Audio detection |
|
Event Monitoring Reporting
|
Manual Report (show event & statistics), Print & Save function, Format ( Excel, PDF, Word) |
|
Event Monitoring Confirming
|
set alarm details normal / abnormal / etc, Confirm action |
|
Event Monitoring History
|
The confirmed details of the selected event from the list |
|
Event Monitoring Instant Viewer
|
display the selecting camera, Confirm the event, Record event remarks and end the event status |
|
Event Monitoring Instant Player
|
Plays the corresponding camera’s video image (DVR / NVR) |
|
Event Monitoring Event Action
|
define various system actions (output) for events (input) from devices, Action (output) types : instant viewer, Preset, Alarm out, Pop-up, sound and e-mail notification |
|
User Management
|
site / user group / user account management, Permission management for viewer functions |
|
Device Management
|
Automatic device IP scanning, Viewing the device settings (Device webpage), Exporting / Importing devices settings, Updating the device firmware |
|
Screen Management Layouts
|
setting / Adding / deleting layouts, Map / video layout |
|
Screen Management Monitor
|
Multi monitor, split screen, sequence, Using i-frame, Using low-resolution, deblocking |
|
Environment
|
Osd display, date/time, Capture, Recording, start up, Language, Ui auto lock, Log |
|
System Settings
|
Back up/Restore ssM setups, Restore the default settings |
|
Time Synchronization
|
NTP server, Client |
|
Update
|
Automatic self upgrade (Connection to Samsung upgrade server) |
|
Supported Device
|
samsung's N/W camera, encoder, dvR / NvR |
|
Max. number of Media gateways per System
|
default 4 media gateway |
|
Max. number of Cameras per Media gateway
|
N/W camera 72CH or dvR / NvR 288CH (36ea) |
|
Max. number of Clients per Media gateway
|
5 clients |
|
Modules
|
system manager, Media gateway, Console, service manager, schedule back up |
|
Language
|
Total 23 languages support english, French, German, spanish, italian, Russian, Chinese, Japanese, Korean, Turkish, Polish, Czech, serbian, Romanian, Portuguese, dutch, Croatian, Hungarian, Greek, swedish, danish, Finnish, Norwegian |
|
System Requirement (Recommended)
|
CPU intel i7 (sandy bridge) above RAM 4GB above, video memory 1GB above, Hdd more than 20GB of free space for installation. (For operation, the system log database requires 10GB or more free space.), directX 8.1 above. display resolution : 1280 x 1024 above, OpenGL compatible |
|
System requirement Minimum
|
CPU intel Core 2 duo 2.83 GHz above, RAM 2GB above, video memory 512MB |
|
System requirement operating System
|
Console (Windows XP 32bit, Windows 7 32/64bit, Windows 8 32/64bit) system mananger, Media gateway (Windows XP 32bit, Windows 7 32/64bit, Windows 8 32/64bit, Windows server 2003, Windows server 2008) |
