| VIDEO |
|
| Imaging Device |
1/1.8" 6M CMOS |
| Total Pixels |
6megapixel (3,096 x 2,094) |
| Effective Pixels |
2,592(H) x 1,944(V) |
| Scanning System |
Progressive |
| Min. Illumination |
Color :
0.2Lux (1/20sec, F1.2, 50IRE), 0.005Lux (2sec, F1.2, 50IRE)
0.1Lux (1/20sec, F1.2, 30IRE), 0.0025Lux (2sec, F1.2, 30IRE)
B/W :
0.02Lux (1/20sec, F1.2, 50IRE), 0.0005Lux (2sec, F1.2, 50IRE)
0.01Lux (1/20sec, F1.2, 30IRE), 0.00025Lux (2sec, F1.2, 30IRE) |
| S / N Ratio |
50dB |
| Video output |
CVBS : 1.0 Vpp / 75Ω composite, 720 x 576, for installation
DIP connector type |
| LENS |
|
| Focus Control |
Simple focus / Manual, Remote control via network, Button control (Manual, Simple focus) |
| Lens Type |
Manual / DC auto iris |
| Mount Type |
C / CS |
| OPERATIONAL |
|
| Camera Title |
Off / On (Displayed up to 15 characters) |
| Day & Night |
Auto (ICR) / Color / B/W / External / Schedule |
| Backlight Compensation |
Off / BLC |
| Contrast Enhancement (DWDR) |
SSDR (Off / On) |
| Digital Noise Reduction |
SSNR (2D+3D noise filter) (Off / On) |
| Motion Detection |
Off / On (4ea, Rectanglular zones) |
| Privacy Masking |
Off / On (32 zones of rectangular) |
| Gain Control |
Off / Low / Middle / High |
| White Balance |
ATW / AWC / Manual / Indoor / Outdoor (Include mercury) |
| Electronic Shutter Speed |
Minimum / Maximum / Anti flicker (2 ~ 1/12,000sec) |
| D-PTZ |
16x, Digital PTZ (Preset, Group) |
| Flip / Mirror |
Off / On |
| Intelligent Video Analytics |
Tampering, Audio detection |
| Alarm I/O |
Input 1ea / Output 1ea |
| Remote Control Interface |
RS-485 |
| RS-485 Protocol |
Samsung-T/E, Pelco-P/D, Sungjin, Panasonic, Honeywell, AD, Vicon, GE, Bosch |
| Alarm Triggers |
Motion detection, Tampering, Audio detection, Alarm input, Network disconnection |
| Alarm Events |
File upload via FTP and E-mail, Notification via E-mail, TCP and HTTP
Local storage (SD/SDHC/SDXC) or NAS recording at Network disconnected &
Event (Alarm triggers), External output |
| NETWORK |
|
| Ethernet |
RJ-45 (10/100BASE-T) |
| Video Compression Format |
H.264 (MPEG-4 part 10/AVC), MJPEG |
| Resolution |
5M mode : 2592 x 1944, 1920 x 1080, 1600 x 1200, 1280 x 1024, 1280 x 960,
1280 x 720, 1024 x 768, 800 x 600, 720 x 576, 720 x 480, 640 x 480, 320 x 240
2M mode : 1920 x 1080, 1280 x 1024, 1280 x 960, 1280 x 720, 1024 x 768,
800 x 600, 720 x 576, 720 x 480, 640 x 480, 320 x 240 |
| Max. Framerate |
5M mode - H.264 : 20fps for all resolution
MJPEG : 2592 x 1944 : 10fps
1920 x 1080, 1600 x 1200, 1280 x 1024, 1280 x 960, 1280 x 720, 1024 x 768 : 15fps
800 x 600, 720 x 576, 720 x 480, 640 x 480, 320 x 240 : 20fps
2M mode - H.264 : 30fps for all resolution
MJPEG : 1920 x 1080, 1280 x 1024, 1280 x 960, 1280 x 720, 1024 x 768 : 15fps
800 x 600, 720 x 576, 720 x 480, 640 x 480, 320 x 240 : 20fps |
| Video Quality Adjustment |
H.264 : Compression level, Target bitrate level control, MJPEG : Quality level control |
| Bitrate Control Method |
H.264 : CBR or VBR, MJPEG : VBR |
| Streaming Capability |
Multiple streaming (Up to 6 profiles) |
| Audio In |
Selectable (Mic in / Line in) (Built-in mic) |
| Audio out |
Supply voltage : 2.5V DC (4mA), Input impedance : approx. 2K Ohm |
| Audio Compression Format |
G.711 u-law/G.726 selectable, G.726 (ADPCM) 8KHz, G.711 8KHz
G.726 : 16Kbps, 24Kbps, 32Kbps, 40Kbps |
| Audio Communication |
Bi-directional audio |
| IP |
IPv4, IPv6 |
| Protocol |
TCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTCP, RTSP, NTP, HTTP, HTTPS, SSL/TLS, DHCP, PPPoE, FTP,
SMTP, ICMP, IGMP, SNMPv1/v2c/v3(MIB-2), ARP, DNS, DDNS, QoS, PIM-SM, UPnP, Bonjour |
| Security |
HTTPS(SSL) login authentication, Digest login authentication
IP address filtering, User access log, 802.1x authentication |
| Streaming Method |
Unicast / Multicast |
| Max. User Access |
10 users at unicast mode |
| Edge Storage |
micro SD/SDHC/SDXC (64GB) - Motion images recorded in the SDXC/SDHC/SD
memory card can be downloaded, NAS (Network Attached Storage) |
| Application Programming Interface |
ONVIF profile S, SUNAPI (HTTP API), SVNP 2.0, Wisenet Open Platform |
| Webpage Language |
English, French, German, Spanish, Italian, Chinese, Korean, Russian, Japanese,
Swedish, Danish, Portuguese, Turkish, Polish, Czech, Rumanian, Serbian, Dutch,
Croatian, Hungarian, Greek, Norwegian, Finnish |
| Web Viewer |
Supported OS : Windows XP / VISTA / 7 / 8, MAC OS X 10.7
Supported Browser : Microsoft Internet Explorer (Ver. 8 ~ 11),
Mozilla Firefox (Ver. 9 ~ 19), Google Chrome (Ver. 15 ~ 25),
Apple Safari (Ver. 6.0.2 (Mac OS X 10.8, 10.7 only), 5.1.7) * Mac OS X only |
| Central Management Software |
SmartViewer, SSM |
| ENVIRONMENTAL |
|
| operating Temperature / Humidity |
-10°C ~ +55°C (+14°F ~ +131°F) / Less than 90% RH |
| Storage Temperature / Humidity |
-30°C ~ +60°C (-22°F ~ +140°F) / Less than 90% RH |
| ELECTRICAL |
|
| Input Voltage / Current |
24V AC ±10%, 12V DC ±10%, PoE (IEEE802.3af, Class3) |
| Power Consumption |
Max. 12.65W (24V AC, 50/60Hz), Max. 10.68W (12V DC), Max. 12.14W (PoE, Class3) |
| MECHANICAL |
|
| Color / Material |
Black, Ivory / Aluminium |
| Dimensions (WxHxD) |
73.1 x 66.6 x 147.0mm (2.88" x 2.62" x 5.79") |
| Weight |
566g (1.25 lb) |
