VIDEO |
|
Imaging Device |
1/2.8" 2.38M CMOS |
Total Pixels |
1,952(H) x 1,116(V) |
Effective Pixels |
1,944(H) x 1,104(V) |
Scanning System |
Progressive |
Min. Illumination |
Color : 0.5Lux (1/30sec, F2.5, 50IRE) |
Video output |
CVBS : 1.0 Vpp / 75Ω composite, 720 x 576, for installation DIP connector type |
LENS |
|
Focus Control |
4.6mm pinhole |
Max. Aperture ratio |
F2.5 |
Angular Field of View |
H : 71° / V : 38° |
Min. Object Distance |
0.3m (0.98ft) |
Mount Type |
RJ-12 connected with main unit |
OPERATIONAL |
|
Camera Title |
Off / On (Displayed up to 45 characters) |
Day & Night |
Auto (Electrical) / Color / B/W / Schedule |
Backlight Compensation |
Off / BLC / WDR |
Wide Dynamic Range |
120dB |
Contrast Enhancement |
SSDR (Samsung Super Dynamic Range) (Off / On) |
Digital Noise Reduction |
SSNRIII (2D+3D noise filter) (Off / On) |
Digital Image Stabilization |
Off / On |
Defog |
Off / Auto / Manual |
Motion Detection |
Off / On (4ea 4 points polygonal zones) |
Privacy Masking |
Off / On (32 zones with 4 points of polygonal) |
Gain Control |
Off / Low / Middle / High |
White Balance |
ATW / AWC / Manual / Indoor / Outdoor |
Electronic Shutter Speed |
Minimum / Maximum / Anti flicker (2 ~ 1/12,000sec) |
Flip / Mirror |
Off / On |
Intelligent Video Analytics |
Tampering, Virtual line, Enter / Exit, (Dis)Appear, Audio detection, Face detection with metadata |
Alarm I/O |
Input 1ea / Output 1ea |
Alarm Triggers |
Motion detection, Alarm input, Video anaytics, Network disconnection, Audio detection |
Alarm Events |
File upload via FTP and E-mail, Notification via E-mail, Local storage (SD/SDHC/SDXC) or NAS recording at Event (Alarm triggers), External output |
NETWORK |
|
Ethernet |
RJ-45 (10/100BASE-T ) |
Video Compression Format |
H.264 (MPEG-4 part 10/AVC), MJPEG |
Resolution |
1920 x 1080, 1280 x 1024, 1280 x 960, 1280 x 720, 1024 x 768, 800 x 600, 800 x 450, 640 x 480, 640 x 360, 320 x 240, 320 x 180 |
Max. Framerate |
H.264 : Max. 30fps at all resolutions MJPEG : 1920 x 1080, 1280 x 1024, 1280 x 960, 1280 x 720, 1024 x 768 : Max. 15fps 800 x 600, 800 x 450, 640 x 480, 640 x 360, 320 x 240, 320 x 180 : Max. 30fps |
Video Quality Adjustment |
H.264 : Compression level, Target bitrate level control, MJPEG : Quality level control |
Bitrate Control Method |
H.264 : CBR or VBR, MJPEG : VBR |
Streaming Capability |
Multiple streaming (Up to 10 profiles) |
Audio In |
Selectable (Mic in / Line in), Supply voltage : 2.5V DC (4mA), Input impedance : approx. 2K Ohm |
Audio out |
Line out (3.5mm stereo mini jack), Max output level : 1 Vrms |
Audio Compression Format |
G.711 u-law/G.726 selectable, G.726 (ADPCM) 8KHz, G.711 8KHz G.726 : 16Kbps, 24Kbps, 32Kbps, 40Kbps |
Audio Communication |
Bi-directional audio (2-way) |
IP |
IPv4, IPv6 |
Protocol |
TCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTCP, RTSP, NTP, HTTP, HTTPS, SSL/TLS, DHCP, PPPoE, FTP, SMTP, ICMP, IGMP, SNMPv1/v2c/v3(MIB-2), ARP, DNS, DDNS, QoS, PIM-SM, UPnP, Bonjour |
Security |
HTTPS(SSL) login authentication, Digest login authentication IP address filtering, User access log, 802.1x authentication |
Streaming Method |
Unicast / Multicast |
Max. User Access |
15 users at unicast mode |
Edge Storage |
micro SD/SDHC/SDXC - motion Images recorded in the SD/SDHC/SDXC memory card can be downloaded. NAS (Network Attached Storage) |
Application Programming Interface |
ONVIF profile S, HTTP API (SUNAPI) 2.0, SVNP 1.2 |
Webpage Language |
English, French, German, Spanish, Italian, Chinese, Korean, Russian, Japanese, Swedish, Danish, Portuguese, Turkish, Polish, Czech, Rumanian, Serbian, Dutch, Croatian, Hungarian, Greek, Finnish, Norwegian |
Web Viewer |
Supported OS : Windows 7, 8, 10, Mac OS X 10.8, 10.9, 10.10, 10.11 Supported Browser : MS Explore 11, Mozilla Firefox 43, Apple Safari 9 * Mac OS X only |
Central Management Software |
SmartViewer, SSM |
ENVIRONMENTAL |
|
operating Temperature / Humidity |
-10°C ~ +55°C (+14°F ~ +131°F) / Less than 90% RH |
Storage Temperature / Humidity |
-30°C ~ +60°C (-22°F ~ +140°F) / Less than 90% RH |
ELECTRICAL |
|
Input Voltage / Current |
PoE (IEEE802.3af), 12V DC |
Power Consumption |
PoE : Max. 7.5W, 12V DC : Max. 6.5W |
MECHANICAL |
|
Color / Material |
Camera header : Black / Plastic, Main unit : Ivory / Plastic |
Dimensions (WxHxD) |
Camera header : Ø24.0 x 42.4mm (Ø0.94" x 1.67"), Main unit : 131.1 x 28.0 x 86.0 (5.16" x 1.1" x 3.39") |
Weight |
Camera unit (Include 1.5m cable) : 80g (0.18 lb), Main unit : 255g (0.56 lb) |
