| Video |
| Imaging Device |
1/2.9" 2M CMOS |
| Total Pixels |
2,000(H) x 1,121(V) 2.24M pixels |
| Effective Pixels |
1,984(H) x 1,105(V) 2.19M pixels |
| Scanning System |
Progressive scan |
| Min. Illumination |
Color : 0.11Lux (F1.4) B/W : 0Lux (IR LED on) |
| S / N Ratio |
52dB (AGC off, Weight on) |
| Video Output |
BNC (AHD, CVBS selectable) |
| Resolution |
1920 x 1080 |
| Max. Framerate |
30fps@1080p, 30fps@720p |
| Lens |
| Focal Length (Zoom Ratio) |
2.8 ~ 12mm (4.3x) varifocal |
| Max. Aperture Ratio |
F1.4 |
| Angular Field of View |
H : 103.8°(Wide) ~ 32.4°(Tele) / V : 53.7°(Wide) ~ 18.4°(Tele) / D : 121.9°(Wide) ~ 37.1°(Tele) |
| Min. Object Distance |
0.5m (1.64ft) |
| Focus Control |
Manual |
| Lens Type |
DC auto iris |
| Mount Type |
Board-in type |
| Pan / Tilt / Rotate |
| Pan / Tilt / Rotate Range |
0° ~ 350° / 0° ~ 67° / 0° ~ 355° |
| Operational |
| On Screen Display |
English, Japanese, Spanish, French, Portuguese, Korean, German, Italian,Russian, Polish, Czech, Romanian, Serbian, Swedish, Danish, Turkish |
| Camera Title |
Off / On (Displayed 15 characters) |
| Day & Night |
Auto (ICR) / Color / B/W |
| Backlight Compensation |
Off / User BLC / HLC |
| Wide Dynamic Range |
DWDR |
| Digital Noise Reduction |
SSNRIV (Off / On) |
| Defog |
Off / Auto / Manual |
| Motion Detection |
Off / On (4 zones) |
| Privacy Masking |
Off / On (4 zones rectangle) |
| Gain Control |
Off / Low / Middle / High / Very high |
| White Balance |
ATW / Outdoor / Indoor / Manual / AWC (1,800K° ~ 10,500K°) |
| Electronic Shutter Speed |
1sec ~ 1/12,000sec |
| Reverse |
Off / H-Rev / V-Rev / HV-Rev |
| Profile |
Basic, Day & Night, Backlight, Indoor, User, ITS |
| Alarm |
(MD) output 1 |
| Remote Control Interface |
Coaxial control |
| Protocol |
Coax : NTSC/PAL - Samsung CCVC, Pelco-C (Coaxitron), AHD - ACP (AHD Coax Protocol) |
| IR Distance |
30m (98.43ft) |
| Video Transmission Distance |
500m (1,640.42ft) (75-5 coaxial cable) |
| Environmental |
| Operating Temperature / Humidity |
-30°C ~ +55°C (-22°F ~ +131°F) / Less than 90% RH *Start up should be done at above -10°C (+14°F) |
| Ingress Protection |
IP66 |
| Vandal Resistance |
IK10 |
| Electrical |
| Input Voltage / Current |
Dual (24V AC & 12V DC ±10%) |
| Power Consumption |
Max. 4.2W |
| Mechanical |
| Color / Material |
Ivory / Aluminum |
| Dimensions (WxHxD) |
Ø137.0 x 106.1mm (Ø5.39" x 4.18") |
| Weight |
716g (1.58 lb) |
