Camera
|
Image Sensor |
1/3 type interline transfer CCD |
Effective Pixels |
976 (H) x 582 (V) |
Scanning Mode |
2:1 interlace |
Scanning Area |
4.8 (H) x 3.6 (V) mm |
Scanning Frequency |
Horizontal: 15.625 kHz Vertical: 50.00 Hz |
Horizontal Resolution |
650 TV lines |
Minimum Illumination |
Color: 0.08 lx (F1.4, Sens Up: Off, AGC: High) B/W: 0.05 lx (F1.4, Sens Up: Off, AGC: High) |
Signal-to-Noise Ratio |
52 dB (AGC: OFF) |
White Balance |
AWC (2,000 ~ 10,000 K), ATW1 (2,700 ~ 8,000 K), ATW2 (2,400 ~ 8,000 K) |
Light Control |
ALC/ALC+/ELC |
AGC |
ON (adjustable), or OFF |
Back Light Compensation |
Preset/Manual (Mask 8 x 6) with Peak mode and level control |
Electronic Shutter |
OFF (1/50), AUTO, 1/120, 1/250, 1/500, 1/1,000, 1/2,000, 1/4,000, 1/10,000, 1/120,000 |
Electronic Sensitivity UP |
32x max. AUTO, 512x max. FIX |
Day & Night |
Day & Night (Electorical) Off / Auto |
Digital Noise Reduction |
High or Low |
Scene File |
2 patterns |
Video Motion Detection |
OFF / MOTION DET / SCENE CHANGE |
Privacy Zone |
ON (1) / ON (2) / OFF, up to 8 zones |
Auto Image Stabilizer |
ON / OFF |
Camera Title |
16 alphanumeric characters |
Synchronization |
Internal (INT) |
Input / Output
|
Video Output |
1.0 V [p-p] / PAL composite 75 |
Controller Interface |
Coaxial Multiplex System |
General
|
Setup Method |
OSD setup menu |
Language
|
English, Russian, German, French, Italian, Spanish, Chinese, Japanese |
Safty/EMC Standard |
CE (EN60065, EN55022 ClassB, EN55024), GOST (GOST R 51558) |
Power Source and Power Consumption |
220-240 V AC, 50/60 Hz, 2.3 W |
Ambient Operating Temperature |
–10 °C ~ +50 °C (14 °F ~ 122 °F) |
Ambient Operating Humidity |
90 % or less (without condensation) |
Dimensions
|
72 mm (W) x 55 mm (H) x 101 mm (D) |
Mass (approx.) |
180g |
Finish |
ABS resin / Sail White |
