Camera
|
Image Sensor |
1/2 inch interline transfer CCD |
| Effective Pixels |
752 (H) x 582 (V) |
| Scanning Mode |
2:1 interlace scan |
| Scanning Area |
6.4 (H) x 4.8 (V) mm |
| Scanning Frequency |
Horizontal: 15.625 kHz Vertical: 50.00 Hz |
| Scanning Line |
625 lines |
| Horizontal Resolution |
540 TV lines typical at color high mode, 480 TV lines at color normal mode, 570 TV lines at B/W mode |
| Minimum Illumination |
Color (30 IRE): 0.09 lux (SENS UP: OFF), 0.003 lux* (SENS UP: 32x) at F1.4 B/W (10 IRE): 0.008 lux (SENS UP: OFF), 0.0003 lux* (SENS UP: 32x) at F1.4 |
| Signal-to-Noise Ratio |
50 dB (AGC Off, Weight On) |
| White Balance |
ATW1, ATW2, or AWC |
| Light Control |
ALC / ALC + (Integration of ALC and ELC) / ELC with Peak mode |
| AGC |
ON (adjustable), or OFF |
| Back Light Compensation |
Preset/Manual (Mask 8 x 6) with Peak mode and level control |
| Electronic Shutter |
OFF (1/50), 1/120, 1/250, 1/500, 1/1,000, 1/2,000, 1/4,000, 1/10,000 s |
| Electronic Sensitivity UP |
OFF / AUTO (2x, 4x, 6x, 10x, 16x, 32x) / FIX (2x, 4x, 6x, 10x, 16x, 32x, 64x, 128x) |
| Digital Noise Reduction |
High / Mid / Low |
| Resolution Mode |
Normal / High |
| Black and White Mode |
Mode: AUTO1 / AUTO2 / ON / OFF, Level: High / Low, with external control |
| Video Motion Detection |
OFF / Mode1 (VMD) / Mode2 (Scene change), Mask 8 x 6 areas |
| Scene Change Detection |
Yes, Included in VMD Mode2 |
| Privacy Zone |
ON (Gray/Mosaic) or OFF |
| Auto Image Stabilizer |
ON / OFF |
| Mirror |
ON / OFF |
| Camera Title |
Up to 16 characters |
| Lens Mount |
CS-mount |
| Lens ALC Drive |
DC / Video |
| Back Focus Adjustment |
ABF, MANUAL, AUTO / PRESET / FIX |
| Synchronization |
Internal (INT), Multiplexed Vertical Drive (VD2), Line-Lock (LL), External (VBS/VS) |
|
Input / Output
|
Video Output |
1.0 V [p-p] / PAL composite 75 ? / BNC Connector Multiplexed VD2 and control data capable (CL model only) |
| External Sync Input |
Gen-Lock input |
| RS-485 Control IF |
CLR model only |
| External I/O Terminals |
Alarm output, Day/Night input |
|
General
|
Setup Method |
OSD setup menu |
|
Language
|
English, Russian (For setup menu and camera title), German, French, Italian, Spanish (For setup menu), Japanese (Only for camera title. Setup menu will be English.) |
| Safty/EMC Standard |
CE (EN60065, EN55022 ClassB, EN55024), GOST (GOST R 51558) |
| Power Source and Power Consumption |
24 V AC 50 Hz: 4.0 W (4.5 W) 12 V DC 340 mA (410 mA) |
| Ambient Operating Temperature |
–10 °C ~ +50 °C (14 °F ~ 122 °F) |
| Ambient Operating Humidity |
90 % or less (without condensation) |
|
Dimensions
|
70 mm (W) x 65 mm (H) x 151 mm (D) (2-3/4" (W) x 2-9/16" (H) x 5-15/16" (D)) |
| Weight (approx.) |
570 g (1.25 lbs.) |
