Camera
|
Image Sensor |
1/3 type interline transfer CCD |
| Effective Pixels |
976 (H) x 582 (V) |
| Scanning Mode |
2:1 interlace |
| Scanning Area |
4.8 (H) x 3.6 (V) mm |
| Scanning Frequency |
Horizontal: 15.625 kHz Vertical: 50.00 Hz |
| Horizontal Resolution |
650 TV lines typ. |
| Minimum Illumination |
Color : 0.08 lx(color mode) B/W: 0.008 lx (black-and-white mode) |
| Signal-to-Noise Ratio |
52 dB (AGC: OFF) |
| White Balance |
AWC (2,000 ~ 10,000 K), ATW1 (2,700 ~ 6,000 K), ATW2 (2,000 ~ 6,000 K) |
| Light Control |
ALC/ALC+/ELC |
| AGC |
ON (LOW, MID, HIGH) / OFF |
| Super Dynamic 6 |
ON / OFF |
| Dynamic Range |
54 dB typical (Super Dynamic 6 : ON) |
| Electronic Shutter |
OFF (1/50), 1/120, 1/250, 1/500, 1/1000, 1/2000, 1/4000, 1/10000, 1/120000 (s) |
| Electronic Sensitivity UP |
32x max. AUTO, 512x max. FIX |
| Day Night |
Day & Night (IR) AUTO1/AUTO2/ON/OFF |
| Digital Noise Reduction |
high or low |
| Scene File |
2 patterns |
| Video Motion Detection |
OFF / MOTION DET / SCENE CHANGE |
| Privacy Zone |
ON (1) / ON (2) / OFF |
| Image Stabilizer |
ON / OFF |
| Camera Title |
16 alphanumeric characters |
| Auto Focus |
AUTO BACK FOCUS/MANUAL |
| Synchronization |
Internal (INT) |
|
Lens
|
Focal Length |
2.8 mm ~ 10.0 mm |
| Zoom Ration |
3.6x |
| Angular Field of View |
H: 100.8° (Wide) ~ 27.6° (Tele) V: 73.8° (Wide) ~ 20.7° (Tele) |
| Maximum Aperture Ratio |
1:1.3 (Wide) ~ 3.0 (Tele) |
| Focusing Range |
0.3 m (0.98 ft.) ~ ∞ |
|
Input / Output
|
Video Output |
1.0 V [p-p] / PAL composite 75 |
| Controller Interface |
Coaxial Multiplex System |
|
General
|
Setup Method |
OSD setup menu |
| Language |
English, French, Italian, Spanish, German, Russian, Chinese, Japanese |
| Safty/EMC Standard |
CE (EN55022 ClassB, EN55024), GOST (GOST R 51558) |
| Power Source and Power Consumption |
24 V AC: 2.5 W, 12 V DC: 220 mA |
| Ambient Operating Temperature |
–10 °C ~ +50 °C (14 °F ~ 122 °F) |
| Ambient Operating Humidity |
90 % or less (without condensation) |
| Dimensions |
ø108 x 94 mm (H) (ø4-1/4" x 3-3/4" (H)) |
| Mass (approx.) |
320 g |
| Finish |
ABS resin / Sail White |
