Image Sensor
|
1/3'' PICADIS |
|
Signal System
|
PAL/NTSC |
|
Effective Pixels
|
1280 (H) × 960 (V) |
|
Min.Illumination
|
0.1Lux @ (F1.2,AGC ON),0 Lux with IR |
|
Shutter Time
|
1/25(1/30) s to 1/25,000(1/30,000) s |
|
Lens
|
3.6mm (2.8mm,6mm,8mm optional) Angle of view: 71.4°(3.6mm) |
|
Lens Mount
|
M12 |
|
Adjustment Range
|
Pan: 0 - 360°, Tilt: 0 - 75°, Rotation: 0 - 360° |
|
Day/Night
|
IR cut filter with auto switch |
|
Horizontal Resolution
|
720TVL |
|
Synchronization
|
Internal Synchronization |
|
Video Output
|
1Vp-p Composite Output (75Ω/BNC) |
|
S/N Ratio
|
More than 62 dB |
|
BLC
|
On |
|
Operating Conditions
|
-40 °C - 60 °C (-40 °F - 140 °F) Humidity 90% or less (non-condensing) |
|
Power Supply
|
12 V DC±10% |
|
Power Consumption
|
Max. 5 W |
|
Weather-proof
|
IP66 |
|
IR Range
|
Approx 10 to 20 meters |
|
Dimension
|
Φ114.6× 89.1mm(Φ4.5” × 3.5”) |
|
Weight
|
300 g (0.66 lbs) |
