Two-way audio input
|
1-ch, RCA (2.0 Vp-p, 1 kΩ) (using the audio input) |
|
IP video input
|
4Ch |
|
Incoming bandwidth
|
40mbps |
|
Outgoing bandwidth
|
80Mbps |
|
Audio Output
|
1-ch, RCA (Linear, 1kΩ) |
|
VGA Output
|
1-ch, resolution: 1920*1080P/60Hz, 1280*1024/60Hz, 1280*720/60Hz, 1024*768/60Hz |
|
Capability
|
4-ch@1080P |
|
Live view / Playback resolution
|
8MP/6MP/5MP/3MP/1080p/UXGA/720p/VGA/4CIF/DCIF/2CIF/CIF/QCIF |
|
SATA
|
1 SATA interface |
|
Capacity
|
Up to 6TB capacity for each HDD |
|
Network interface
|
1, RJ45 10M / 100M Ethernet interface |
|
USB interface
|
2, USB2.0 |
|
Interface
|
4 independent 10 /100 Mbps PoE Ethernet interfaces |
|
Power Supply
|
48 VDC |
|
Consumption
|
≤ 10 W |
|
Working Temperature/Humidity
|
-10 oC ~ +55 oC (+14 oF~ + 131 oF) |
|
Chassis
|
315 mm chassis |
|
Dimension
|
315 × 240 × 48 mm (12.4" × 9.4" × 1.9") |
|
Weight
|
1Kg (2.2 lb) |
