HIKVISION DS-7316HQHI-F4/N

tidak termasuk pengiriman

• H.264 /H.264+& Dual-stream video compression
• Support HD-TVI, IPC,AHD and analog cameras with adaptive access
• Support Cloud storage(One Drive, Google Drive or Drop Box)
• Up to 3 MP resolution for recording of the first 4 channels
• VGA output at up to 1920×1080P resolution,HDMI output at up to 4K(3840x2160) resolution
• Long transmission distance over coax cable
• Up to 16-ch synchronous playback at 1080p resolution
• Playback at up to 256X speed
• Support POS functions.

Qty:

Overview
Contact Us

Jual DVR HIKVISION DS-7316HQHI-F4/N dengan harga murah, kompetitif dan terjangkau di JakartaCCTV. DVR (Digital Video Recorder) HIKVISION seri Turbo HD 7300 ini dapat menerima audio input dari 4 channel dan dihubungkan ke IP Camera (2 channel) dan HD-TVI & Analog Camera (16 channel). Channel channel ini kemudian bisa dikonfigurasi secara independen yang meliputi resolusi video, frame rate video, bit rate video, kualitas gambar video, dsb. Konfigurasi lain yang juga disupport adalah konfigurasi sensitivitas cahaya dari siang ke malam hari dan dari malam ke siang hari, serta konfigurasi terangnya cahaya infra merah, selama kamera perekam mensupport pula parameter tsb, sehingga bisa dikatakan DVR ini dapat mengoptimalkan fitur fitur dari kamera selama perekaman.

Video dan audio yang direkam oleh DVR ini dapat di streaming dan ditampilkan pada ouput HDMI/VGA dan diputar ulang secara sinkron pada 16 channel dengan resolusi hngga 1080p. Video yang direkam tersimpan dalam 4 SATA Hard Disk Drive dengan kapasitas 6 TB tiap disk. Selain itu, DVR ini juga mengadopsi teknologi watermark, yang menginjinkan penggunanya untuk menyematkan informasi digital pada video yang direkam (yang biasanya berfungsi untuk memproteksi hak cipta dari perekam).

FITUR & FUNGSI HIKVISION DS-7316HQHI-F4/N

H.264 /H.264+& Dual-stream video compression

Support HD-TVI, IPC,AHD and analog cameras with adaptive access
Support Cloud storage(One Drive, Google Drive or Drop Box)
Up to 3 MP resolution for recording of the first 4 channels
VGA output at up to 1920×1080P resolution,HDMI output at up to 4K(3840x2160) resolution
Long transmission distance over coax cable
Up to 16-ch synchronous playback at 1080p resolution
Playback at up to 256X speed
Support POS functions.

Selain garansi resmi selama 2 tahun dari distributor HIKVISION di Indonesia, anda juga akan mendapatkan tips yang aman dan berguna dalam memilih, membeli & memasang Digital Video Recorder HIKVISION yang sesuai dengan kebutuhan anda dengan harga distributor yang murah jika anda membeli produk ini dari kami, JakartaCCTV. Jadi tunggu apalagi ? Hubungi kami sekarang untuk mendapatkan DVR HIKVISION DS-7316HQHI-F4/N ini atau jika anda masih memiliki pertanyaan lebih lanjut mengenai produk ini atau paket CCTV kami lainnya.

Video/Audio Input
Audio Input	4-ch
Video Compression	H.264,H.264+
Analog and HD-TVI video input	16-ch,BNC interface (1.0Vp-p, 75 Ω)connection
Supported camera types	Support HDTVI input: 3 MP, 1080p/25Hz, 1080p/30Hz, 720p/25Hz, 720p/30Hz, 720P/50Hz, 720p/60Hz Note: The 3 MP signal input is only available for the first 4 channels Support AHD input: 1080p/25Hz, 1080p/30Hz, 720p/25Hz, 720p/30Hz support CVBS input
IP Video Input	2-ch Up to 4MP resolution
Video Input Interface	BNC (1.0 Vp-p, 75Ω)
Audio Compression	G.711u
Audio Input Interface	4-ch, RCA (2.0 Vp-p, 1 kΩ)
Two-way Audio	1-ch, RCA (2.0 Vp-p, 1 KΩ) (using audio input)
Video/Audio Output
CVBS Output	1-ch,BNC(1.0Vp-p,75Ω),resolution:PAL:704x576,NTSC:704x480
HDMI/VGA Output	HDMI: 1-ch,4K(3840×2160)/30Hz,2K(2560×1440)/60Hz, 1920×1080/60Hz, 1280×1024/60Hz,1280×720/60Hz,1024 ×768/60Hz VGA:1-ch,2K(2560×1440)/60Hz,1920×1080/60Hz,1280×1024/60Hz,1280×720/60Hz,1024×768/60Hz
Recording resolution	When 1080p Lite mode not enabled: 3 MP/1080p/720p/VGA/WD1/4CIF/CIF; When 1080p Lite mode enabled: 3 MP/1080p lite/720p/VGA/WD1/4CIF/CIF
Frame Rate	Main stream: When 1080p Lite mode not enabled: For 3 MP stream access: 3 MP/1080p/720p/VGA/WD1/4CIF/CIF@12fps For 1080p stream access: 1080p/720p@12fps; VGA/WD1/4CIF/CIF@25fps (P)/30fps (N) For 720p stream access: 720p/VGA/WD1/4CIF/CIF@25fps (P)/30fps (N) When 1080p Lite mode enabled: 3 MP/1080p lite/720p/VGA/WD1/4CIF/CIF@25fps (P)/30fps (N)
Video Bit Rate	32 Kbps-6 Mbps
Stream Type	Video/Video&Audio
Audio Output	1-ch RCA(Linear, 1kΩ)
Audio Bit Rate	64kbps
Dual Stream	Support
Playback Resolution	3 MP/1080p/720p/VGA/WD1/4CIF/CIF
Synchronous Playback	16-ch
Network management
Remote connections	128
Network protocols	TCP/IP, PPPoE, DHCP,Hik Cloud P2P, DNS, DDNS, NTP, SADP, SMTP, NFS, iSCSI, UPnP™, HTTPS,ONVIF
Hard Disk Driver
Interface Type	4 SATA Interface
Capacity	Up to 6 TB capacity for each disk
External Interface
Network Interface	1; 10M / 100M self-adaptive Ethernet interface
USB Interface	Front panel : 2 × USB 2.0 Rear panel : 1 × USB 3.0
Serial Interface:	RS-232, RS-485 (full-duplex), Keyboard
Alarm in/out	16/4
General
Power Supply	100 to 240 VAC
Consumption	≤ 55W(without hard disks)
Working Temperature	-10 ºC ~+55 ºC (14 ºF ~ 131 ºF)
Working Humidity	10% ~ 90%
Chassis	Standalone 1U chassis
Dimensions	445 × 390 × 70 mm (17.5 × 15.4 × 2.8 inch)
Weight	≤5 kg(11.0lb)
