Video/Audio Input |
|
Audio Input |
1-ch |
Video Compression |
H.264,H.264+ |
Analog and HD-TVI video input |
8-ch,BNC interface (1.0Vp-p, 75 Ω)connection |
Supported camera types |
Support HDTVI input: 3 MP, 1080p/25Hz, 1080p/30Hz, 720p/25Hz, 720p/30Hz, 720P/50Hz, 720p/60Hz Note: The 3 MP signal input is only available for the first 2 channels Support AHD input: 1080p/25Hz, 1080p/30Hz, 720p/25Hz, 720p/30Hz support CVBS input |
IP Video Input |
2-ch Up to 2MP resolution |
Video Input Interface |
BNC (2.0 Vp-p, 75Ω) |
Audio Compression |
G.711u |
Audio Input Interface |
RCA (2.0 Vp-p, 1 kΩ) |
Two-way Audio |
1-ch, RCA (2.0 Vp-p, 1 KΩ) (using audio input) |
Video/Audio Output |
|
CVBS Output |
1-ch,BNC(1.0Vp-p,75Ω),resolution:PAL:704x576,NTSC:704x480 |
HDMI/VGA Output |
1920 × 1080 / 60 Hz,1280 × 1024 / 60 Hz, 1280 × 720 / 60 Hz, 1024 × 768 / 60 Hz |
Recording resolution |
When 1080p Lite mode not enabled: 3 MP/1080p/720p/VGA/WD1/4CIF/CIF; When 1080p Lite mode enabled: 3 MP/1080p lite/720p/VGA/WD1/4CIF/CIF |
Frame Rate |
Main stream: When 1080p Lite mode not enabled: For 3 MP stream access: 3 MP/1080p/720p/VGA/WD1/4CIF/CIF@12fps For 1080p stream access: 1080p/720p@12fps; VGA/WD1/4CIF/CIF@25fps (P)/30fps (N) For 720p stream access: 720p/VGA/WD1/4CIF/CIF@25fps (P)/30fps (N) When 1080p Lite mode enabled: 3 MP/1080p lite/720p/VGA/WD1/4CIF/CIF@25fps (P)/30fps (N) |
Video Bit Rate |
32 Kbps-6 Mbps |
Stream Type |
Video/Video&Audio |
Audio Output |
1-ch RCA(Linear, 1kΩ) |
Audio Bit Rate |
64kbps |
Dual Stream |
Support |
Playback Resolution |
3 MP/1080p/720p/VGA/WD1/4CIF/CIF |
Synchronous Playback |
8-ch |
Network management |
|
Remote connections |
128 |
Network protocols |
TCP/IP, PPPoE, DHCP,Hik Cloud P2P, DNS, DDNS, NTP, SADP, SMTP, NFS, iSCSI, UPnP™, HTTPS,ONVIF |
Hard Disk Driver |
|
Interface Type |
2 SATA Interface |
Capacity |
Up to 6 TB capacity for each disk |
External Interface |
|
Network Interface |
1; 10M / 100M self-adaptive Ethernet interface |
USB Interface |
2 USB 2.0 Interfaces |
Serial Interface: |
1; standard RS-485 serial interface, half-duplex |
General |
|
Power Supply |
12V DC |
Consumption |
≤ 20W(without hard disks) |
Working Temperature |
-10 ºC ~+55 ºC (14 ºF ~ 131 ºF) |
Working Humidity |
10% ~ 90% |
Chassis |
380mm 1U chassis |
Dimensions |
315 × 242 × 45 mm (12.4 × 9.5 × 1.8 inch) |
Weight |
≤2 kg(4.4lb) |
