Video Audio/Input
|
| Audio Input |
4-ch |
| Video Compression |
H.264,H.264+ |
| Analog and HD-TVI video input |
16-ch,BNC interface (1.0Vp-p, 75 Ω)connection |
| Supported camera types |
Support HDTVI input: 5MP,4MP,3MP,1080P/25Hz, 1080P/30Hz,720P/25Hz, 720P/30Hz, 720P/50Hz, 720P/60Hz,
Support AHD input: 1080P/25Hz, 1080P/30Hz, 720P/25Hz, 720P/30Hz
Support CVBS input |
| Video Input Interface |
BNC (1.0 Vp-p, 75Ω) |
| Audio Compression |
G.711u |
| Audio Input Interface |
4-ch, RCA (2.0 Vp-p, 1 KΩ) |
| Two-way Audio |
1-ch, RCA (2.0 Vp-p, 1 KΩ), (using the 1st channel of audio input) |
|
Video Audio/Output
|
| CVBS Output |
1-ch,BNC(1.0Vp-p,75Ω),resolution:PAL:704x576,NTSC:704x480 |
| HDMI/VGA Output |
HDMI: 1-ch,4K(3840×2160)/30Hz,2K(2560×1440)/60Hz, 1920×1080/60Hz, 1280×1024/60Hz,1280×720/60Hz,1024 ×768/60Hz
VGA:1-ch,2K(2560×1440)/60Hz,1920×1080/60Hz,1280×1024/60Hz,1280×720/60Hz,1024×768/60Hz |
| Recording resolution |
Mainstream:5MP/4MP/3Mp/1080p/720p/WD1/4CIF/VGA/CIF
Sub-stream:WD1/4CIF/CIF/QVGA/QCIF |
| Frame Rate |
Main stream:
5MP@10fps/4MP@15fps/3MP@15fps/1080p/720p/WD1/4CIF/VGA/CIF@25fps (P)/30fps (N)
Sub-stream:
WD1/4CIF@12fps;CIF/QVGA/QCIF@25fps (P)/30fps (N) |
| Video Bit Rate |
32 Kbps-10 Mbps |
| Stream Type |
Video/Video&Audio |
| Two-way Audio |
1-ch, RCA (2.0 Vp-p, 1 kΩ) (using the audio input) |
| Audio Output |
1-ch RCA(Linear, 1kΩ) |
| Audio Bit Rate |
64kbps |
| Dual Stream |
Support |
| Playback Resolution |
5MP/4MP/3MP/1080p/720p/VGA/WD1/4CIF/CIF/QVGA/QCIF |
| Synchronous Playback |
16-ch |
|
Network Management
|
| Remote Connections |
128 |
| Network Protocols |
TCP/IP, PPPoE, DHCP, Hik Cloud P2P, DNS, DDNS, NTP, SADP, NFS, iSCSI, UPnP™, HTTPS,
ONVIF |
|
Hard Disk Driver
|
| Interfacce Type |
2 SATA Interface |
| Capacity |
Up to 6 TB capacity for each disk |
|
External Interface
|
| Network Interface |
1; 10M / 100M / 1000M self-adaptive Ethernet interface |
| USB Interface |
2 USB 2.0 Interface on the front panel& 1 USB 3.0 Interface on the rear panel |
| Alarm Input |
16-ch |
| Alarm Output |
4-ch |
|
General
|
| Power Supply |
12V DC |
| Consumption |
≤ 25W(without hard disks) |
| Working Temperature |
-10 ºC ~+55 ºC (14 ºF ~ 131 ºF) |
| Working Humidity |
10% to 90% |
| Chassis |
380mm 1U chassis |
| Dimensions |
380 × 320 × 48 mm (15.0 × 12.6 × 1.9 inch) |
| Weight |
≤2kg(4.4lb) |
