Hikvision DS-2DE3204W- [2MP Network Mini PTZ Dome Camera]

Image Sensor:

1/3" progressive scan CMOS

Effective Pixels:

1920(H)x1080(V)

Minimum Illumination:

F1.6, AGC On : Color : 0.05 lux, B/W : 0.01 lux

White Balance:

Auto/Manual/ATW/Indoor/Outdoor/Daylight lamp/Sodium lamp

AGC:

Auto/Manual

BLC:

ON/OFF

HLC:

Support

WDR:

Support

Shutter Time:

1/1~1/10,000s

Day& Night:

ICR

Digital Zoom:

16X

Privacy Masking:

8 privacy masks programmable

Auto Focus:

Auto / Semi-automatic / Manual

Focal Length:

2.8~12mm, 4x

Zoom Speed:

Approx.1s(Wide~Tele)

Angle of View:

105~33.5 degree (Wide~Tele)

Aperture Range:

F1.6 ~F2.7

Range:

Pan: 0~350°

Speed:

Pan Manual Speed: 0.1°~60°/s

Tilt Range:

Tilt: 0°~90°

Tilt Speed:

Tilt Manual Speed: 0.1°~50°/s

Proportional Zoom:

Rotation speed can be adjusted automatically according to zoom multiples

Number of Preset:

300

Power loss recovery:

Support

Park Action:

Preset

PTZ Position Display:

ON/OFF

Alarm I/O

1/1

Alarm Action:

Preset, Recording, Relay output, Upload center, Upload FTP, Email linkage

Audio Input:

1 Mic in/Line in interface
Line input: 2-2.4V[p-p]; output impedance: 1KΩ, ±10%

Audio Output:

1 Audio output interface
Line level, impedance: 600Ω

Ethernet:

10Base -T, /100Base-TX, RJ45 Connector

Max.Image Resolution:

1920×1080

Main Stream:

50Hz:25fps (1920×1080,1280×960,1280×720), 50fps (1280×960,1280×720) ;
60Hz:30fps(1920×1080,1280×960,1280×720), 60fps (1280×960,1280×720)

Sub Stream:

50Hz:25fps(704×576), 25fps(640×576), 25fps(320×288)
60Hz:30fps(704×480), 30fps(640×480), 30fps(320×240)

Third Stream:

50Hz: 25fps (1920 × 1080, 1280 × 720, 704 × 576, 640 × 480, 320 × 288)
60Hz: 30fps (1920 × 1080, 1280 × 720, 704 × 480, 640 × 480, 320 × 240)

Image Compression:

H.264 / MJPEG

ROI encoding:

Support 4 areas with adjustable levels

Audio Compression:

G.711ulaw/G.711alaw/G.726/MP2L2/G.722

Protocols:

IPv4/IPv6, HTTP, HTTPS, 802.1X, QoS, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP, RTP, TCP, UDP,IGMP, ICMP, DHCP, PPPoE

No. of Simultaneous Users:

Up to 20 users

Dual Stream:

Support

Mini SD Card:

Support up to 128GB Micro SD/SDHC/SDXC card. Support Edge recording

User/Host Level:

Up to 32 users,3 Levels: Administrator, Operator and User

Security Measures:

User authentication (ID and PW),
Host authentication (MAC address)
IP address filtering

EZVIZ:

Support

Date & Time Display:

Time: Week: Date, 6 formats on the Client

Client:

Support iVMS-4200

Web Browser:

IE 7+, Chrome 18 +, Firefox 5.0 +, Safari 5.02 +

Menu Language:

English

Power Supply:

12V DC or PoE((802.3af, class3)

Power Consumption:

Max. 8W

Working Temp/Humidity:

-30°C ~ 65°C (-22°F ~ 149°F)

Protection Level:

IP67, IK10, TVS 4,000V lightning protection, surge protection and voltage transient protection

Mounting:

Various mounting modes optional

Dimensions:

Φ140.7×107.2mm

Weight (approx.):

950g

Mount Option:

Wall mount: DS-1273ZJ -PT6; In-ceiling Mount: 1227ZJ-PT6; Junction Box: DS-1280ZJ -PT6
