Hikvision DS-2CE56F7T-ITZ
Hikvision DS-2CE56F7T-ITZ – 3MP WDR Indoor Motorized Vf EXIR Dome Camera
3 Megapixel high-performance CMOS
Analog HD output, up to 3MP resolution
2.8-12mm motorized vari-focal lens
True Day/Night
OSD menu, DNR, Smart IR
True WDR, up to 120dB
EXIR technology, up to 40m IR distance
Up the Coax(HIKVISION-C)
Hikvision DS-2CE56F7T- ITZ – 3MP WDR Indoor Motorized Vf EXIR Dome Camera
Jual HIKVISION DS-2CE56F7T – ITZ Indoor Kamera dengan harga yang murah dan terjangkau. CCTV Dome Camera ini memiliki spesifikasi 3 megapixel dengan performa CMOS yang tinggi. Menggunakan Analog HD Output, yang mencapai 3MP resolusi, mempunyai menu OSD, DNR dan Smart IR dan WDR yang mencapai 120Db. Menggunakan teknologi dari EXIR, jarak nya mencapai 40m IR.
Camera
|
Image Sensor |
3MP CMOS Image Sensor |
Effective Pixels |
2052(H)x1536(V) |
Signal System |
PAL/NTSC |
Minimum Illumination |
0.01 Lux @ (F1.2,AGC ON),0 Lux with IR |
Shutter Time |
1/25(1/30) s to 1/50,000 s |
Lens |
Motorized VF lens; 2.8 - 12 mm angel of view: 26.8°-83° |
Lens Mount |
φ14 |
Adjustment Range |
Pan: 0 - 360°, Tilt: 0 - 75°, Rotation: 0 - 360° |
Day& Night |
IR Cut Filter with Auto Switch |
Wide Dynamic Range |
120Db |
Video Frame Rate |
1920 ×1536@18fps |
HD Video Output |
1 Analog HD Output |
Synchronization |
Internal Synchronization |
S/N Ratio |
More than 62 Db |
Up The Coax |
Support |
Menu
|
Auto White Balance |
Auto/MWB |
BLC |
Support |
AGC |
Support |
Language |
English/Chinese |
Function |
Wide Dynamic Range; Digital Noise Reduction; Mirror; Smart IR |
D/N Mode |
Color/BW/SMART |
General
|
Operating Conditions |
-40 °C - 60 °C (-40 °F - 140 °F) Humidity 90% or less (non-condensing) |
Power Supply |
12 VDC±15% -A: 12 VDC±15%, 24 VAC±15% |
Power Consumption |
Max. 4.5W -A: Max. 6.5W |
IR Range |
Up to 30m |
Communication |
Up the coax Protocol: HIKVISION-C(Coaxitron) |
Dimension |
φ136 × 102 mm (φ5.35” × 4.02”) |
Weight |
Approx. 600g |
