Hikvision DS-2CE56F1T - ITM
Hikvision DS-2CE56F1T - ITM – 3MP EXIR Turret Camera
3 Megapixel high-performance CMOS
Analog HD output, up to 3MP resolution
True Day/Night
OSD menu, DNR, Smart IR
EXIR technology, up to 20m IR distance
IP66 Weatherproof
Up the Coax(HIKVISION-C)
Hikvision DS-2CE56F1T- ITM – 3MP EXIR Turret Camera
Jual HIKVISION DS-2CE56F1T – ITM Kamera dengan harga yang murah dan terjangkau. CCTV Turret Camera ini memiliki spesifikasi 3 megapixel dengan performa CMOS yang tinggi. Menggunakan Analog HD Output, yang mencapai 3MP resolusi, mempunyai menu OSD, DNR dan Smart IR dan IP66 anti udara. Menggunakan teknologi dari EXIR, jarak nya mencapai 20m IR.
|
Camera
|
| Image Sensor |
3MP CMOS Image Sensor |
| Effective Pixels |
2052(H)x1536(V) |
| Signal System |
PAL/NTSC |
| Minimum Illumination |
0.01 Lux @ (F1.2,AGC ON),0 Lux with IR |
| Shutter Time |
1/25(1/30) s to 1/50,000 s |
| Lens |
2.8mm, 3.6mm, 6mm, optional
Angle of View: 84°(2.8mm), 67.8°(3.6mm), 44.6°(6mm) |
| Lens Mount |
M12 |
| Adjustment Range |
Pan: 0 - 360°, Tilt: 0 - 75°, Rotation: 0 - 360° |
| Day& Night |
IR Cut Filter with Auto Switch |
| Video Frame Rate |
1920 ×1536@18fps |
| HD Video Output |
1 Analog HD Output |
| Synchronization |
Internal Synchronization |
| S/N Ratio |
More than 62 Db |
| Up The Coax |
Support |
|
Menu
|
| Auto White Balance |
Auto/MWB |
| BLC |
Support |
| AGC |
Support |
| Language |
English/Chinese |
| Function |
Wide Dynamic Range; Digital Noise Reduction; Mirror; Smart IR |
| D/N Mode |
Color/BW/SMART |
|
General
|
| Operating Conditions |
-40 °C - 60 °C (-40 °F - 140 °F)
Humidity 90% or less (non-condensing) |
| Power Supply |
12 VDC±15% |
| Power Consumption |
Max. 5W |
| IR Range |
Up to 20m |
| Communication |
Up the coax
Protocol: HIKVISION-C(Coaxitron) |
| Dimension |
91mm×82.6mm×68.3mm (3.58"×3.25"×2.69") |
| Weight |
Approx. 350g |
| Weather Proof |
IP66 |
