Camera |
|
Image Sensor |
1/3" Progressive Scan CMOS |
Min. Illumination |
0.01Lux @ (F1.2, AGC ON), 0 Lux with IR, 0.014 Lux @(F1.4,AGC ON), 0 Lux with IR |
Shutter time |
1/3 s to 1/10,000 s |
Lens |
-I3: (4mm, 6mm option) @ F1.4, -I5: (4mm, 6mm, 12mm option) @ F1.4, -I8: (6mm, 12mm, 16mm option) @ F1.4, |
Lens Mount |
M12 |
Day& Night |
IR cut filter with auto switch |
Wide Dynamic Range |
Digital WDR |
Digital noise reduction |
3D DNR |
Compression Standard |
|
Video Compression |
H.264/MJPEG/H.264+ |
H.264 code profile |
Main Profile |
Video bit rate |
256Kbps~16Mbps |
Dual Stream |
Yes |
Image |
|
Max. Image Resolution |
2560×1920 |
Main Stream |
50Hz: 20fps (2560×1920), 25fps (2048x1536), 25fps(1920×1080), 25fps(1280×720) 60Hz: 20fps (2560×1920), 30fps (2048x1536), 30fps(1920×1080), 30fps(1280×720) |
Image Settings |
Rotate mode, Saturation, Brightness, Contrast adjustable by client software or web browser |
Network |
|
Network Storage |
NAS (Support NFS,SMB/CIFS), ANR |
Alarm Trigger |
Motion detection, tampering alarm, network disconnect , IP address conflict, storage exception |
Protocols |
TCP/IP, UDP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, Bonjour |
Security |
One-key reset, Anti-Flicker, heartbeat, mirror, password protection, privacy mask, Watermark, IP address filtering |
System Compatibility |
ONVIF (Profile S, Profile G), PSIA, CGI, ISAPI |
Interface |
|
Communication Interface |
1 RJ45 10M / 100M Ethernet interface |
General |
|
Operating Conditions |
-30 °C ~ 60 °C (-22 °F ~ 140 °F) Humidity 95% or less (non-condensing) |
Power Supply |
12 VDC ± 10%, PoE (802.3af) |
Power Consumption |
I3: Max. 6 W, I5: Max. 7.5 W, I8: Max. 10.5 W Max. 9W with pan and tilt |
IR Range |
-I3: 30 meters -I5: 50 meters -I8: 80 meters |
Dimensions |
299.71 × 86.48 × 85.11(11.8’’ × 3.4’’ × 3.35’’) |
Weight |
1200g (2.6 lbs) |
