Camera |
|
Image Sensor |
1/3" Progressive Scan CMOS |
Min. Illumination |
0.01Lux @ (F1.2, AGC ON), 0 Lux with IR, 0.014 Lux @(F1.4,AGC ON), 0 Lux with IR |
Shutter time |
1/3 s to 1/10,000 s |
Slow shutter |
Support |
Lens |
(-I3: 4,6mm; -I5: 4,6,12mm; -I8: 6,12,16mm) @F2.0 angle of view: 83°(4mm), 55.4°(6mm), 24.7°(12mm), 19.1°(16mm) |
Lens Mount |
M12 |
Day& Night |
IR cut filter with auto switch |
Wide Dynamic Range |
120 dB |
Digital noise reduction |
3D DNR |
Compression Standard |
|
Video Compression |
H.264/MJPEG/H.264+ |
H.264 code profile |
Main Profile |
Video bit rate |
32Kbps~16Mbps |
Image |
|
Max. Image Resolution |
2688 × 1520 |
Main Stream |
50Hz: Main stream:20fps(2688×1520),25fps(1920×1080), 25fps(1280×720), Sub stream:25fps(352×288),25fps(640×360) 60Hz: Main stream:20fps(2688×1520),30fps(1920×1080), 30fps(1280×720),Sub stream: 30fps(352×240),30fps(640×360) |
Image Enhancement |
BLC/3D DNR/ROI |
Image Settings |
Rotate mode, Saturation, Brightness, Contrast adjustable by client software or web browser |
Day/Night Switch |
Auto/Schedule/Triggered by Alarm In |
Network |
|
Network Storage |
NAS (Support NFS,SMB/CIFS) |
Alarm Trigger |
Tampering alarm, Network disconnect , IP address conflict, Storage exception |
Protocols |
TCP/IP, UDP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, Bonjour |
Security |
Flash-prevention, dual stream, heartbeat, mirror, password protection, privacy mask, watermark, IP address filtering, Anonymous access |
System Compatibility |
ONVIF (Profile S, Profile G), PSIA, CGI, ISAPI |
Interface |
|
Communication Interface |
1 RJ45 10M / 100M Ethernet interface |
General |
|
Operating Conditions |
-30 °C ~ 60 °C (-22 °F ~ 140 °F) Humidity 95% or less (non-condensing) |
Power Supply |
DC12V ± 25%, PoE (802.3af Class 3) |
Power Consumption |
I3: Max. 6W; I5: Max. 7.5W; I8: Max. 10.5W |
Weather proof |
IP67 |
IR Range |
-I3: 30 meters -I5: 50 meters -I8: 80 meters |
Dimensions |
299.71 × 86.48 × 85.11(11.8’’ × 3.4’’ × 3.35’’) |
Weight |
1200g (2.6 lbs) |
