| Camera |
| Image Sensor |
1/2.8" Progressive Scan CMOS |
| Min. Illumination |
0.01Lux @(F1.2,AGC ON), 0.028Lux @(F2.0,AGC ON), 0 Lux with IR |
| Shutter speed |
1/3 s to 1/10,000 s |
| Lens |
I8 : (6 MM, 12 MM, 16 MM option) @ F1.4, |
| Slow Shutter |
Support |
| Lens |
(I8: 6,12,16 MM) @F2.0 |
| Lens Mount |
M12 |
| Day & Night |
IR cut filter with auto switch |
| WDR |
120dB |
| Compression Standard |
| Video Compression |
H.264/MJPEG/H.264+ |
| H.264 code profile |
Main Profile |
| Video bit rate |
256Kbps~16Mbps |
| Image |
| Max. Image Resolution |
1920 × 1080 |
| Frame Rate |
50Hz : 25fps (1920 × 1080, 1280 × 960, 1280 × 720) 60Hz : 30fps (1920 × 1080, 1280 × 960, 1280 × 720) |
| Image Enhancement |
BLC/3D DNR/RO |
| Image Setting |
Rotate Mode, Saturation, Brightness, Contrast, Sharpness adjustable by client software or web browser |
| Day/Night Switch |
Auto/Schedule/Triggered by Alarm In |
| Network |
| Network Storage |
NAS (Support NFS,SMB/CIFS), ANR |
| Alarm Trigger |
Intrusion Detection, Line Crossing detection, Motion detection, Dynamic Analysis, Tampering alarm, Network disconnect, IP address conflict, Storage exception |
| Protocols |
TCP/IP, UDP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, Bonjour |
| Security |
Flash-prevention, dual stream, heartbeat, mirror, password protection, privacy mask, watermark, IP address filtering, Anonymous access |
| System Compatibility |
ONVIF (Profile S, Profile G), PSIA, CGI, ISAPI |
| Interface |
| Communication Interface |
1 RJ45 10 M / 100 M Ethernet interface |
| General |
| Operating Conditions |
-30 °C ~ 60 °C (-22 °F ~ 140 °F) Humidity 95% or less (non-condensing) |
| Power Supply |
12 VDC ± 10%, PoE (802.3af) |
| Power Consumption |
-I3: Max. 6W; -I5: Max. 7.5W; -I8: Max. 10.5W |
Ingress Protection level |
IP66 |
| IR Range |
80 M |
| Dimensions |
299.71 × 86.48 × 85.11(11.8’’ × 3.4’’ × 3.35’’) |
| Weight |
1200 Gr (2.6 lbs) |
