| Camera |
|
| Image Sensor |
1/2.8" Progressive Scan CMOS |
| Min. Illumination |
0.01Lux @(F1.2,AGC ON), 0.014 Lux @(F1.4,AGC ON), 0 Lux with IR |
| Shutter time |
1/3 s to 1/10,000 s |
| Slow shutter |
Yes |
| Lens |
2.8 - 12 mm @ F1.4, motorized lens (-Z), angle of view: 106°~35° |
| Lens Mount |
φ14 |
| Adjustment Range |
Pan:0° - 355°, Tilt: 0° - 75°, Rotation: 0° - 355° |
| Day& Night |
IR cut filter with auto switch |
| Wide Dynamic Range |
120 dB |
| Digital noise reduction |
3D DNR |
| Compression Standard |
|
| Video Compression |
H.264/MJPEG/H.264+ |
| H.264 code profile |
Main Profile |
| Video bit rate |
32Kbps~16Mbps |
| Audio Compression |
-S: G.711/G.722.1/G.726/MP2L2 |
| Image |
|
| Max. Image Resolution |
1920 x 1080 |
| Frame Rate |
50Hz: 25fps(1920 × 1080, 1280 × 960, 1280 × 720) 60Hz: 30fps (1920 × 1080, 1280 × 960, 1280 × 720) |
| Image Enhancement |
BLC/3D DNR/ROI |
| Image Settings |
Rotate mode, Saturation, Brightness, Contrast adjustable by client software or web browser |
| Day/Night Switch |
Auto/Schedule/Triggered by Alarm In |
| Network |
|
| Network Storage |
Micro SD/SDHC/SDXC card with ANR (up to 128G), NAS (Support NFS, SMB/CIFS) |
| Alarm Trigger |
Line Crossing, Intrusion Detection, Motion detection, Dynamic analysis, Tampering alarm, Network disconnect , IP address conflict, Storage exception |
| Protocols |
TCP/IP,ICMP,HTTP,HTTPS,FTP,DHCP,DNS,DDNS,RTP,RTSP,RTCP, PPPoE,NTP,UPnP,SMTP,SNMP,IGMP,802.1X,QoS,IPv6,Bonjour |
| Security |
One-key reset, Anti-Flicker, heartbeat, mirror, password protection, privacy mask, Watermark, IP address filtering |
| System Compatibility |
ONVIF (Profile S, Profile G), PSIA, CGI, ISAPI |
| Interface |
|
| Communication Interface |
1 RJ45 10M / 100M Ethernet interface |
| General |
|
| Operating Conditions |
-30 °C ~ 60 °C (-22 °F ~ 140 °F) Humidity 95% or less (non-condensing) |
| Power Supply |
12 VDC ± 25%, PoE (802.3af Class3) |
| Power Consumption |
Maximum 5.5 W |
| Impact Protection |
IEC60068-2-75Eh, 50J; EN50102, IK10 |
| Weather Proof |
IP67 |
| IR Range |
Up to 30m |
| Dimensions |
Φ 140 × 99.9 mm (Φ 5.51” × 3.94”) |
| Weight |
1000g (2.20lbs) |
| NOTE |
* “-S” series support 1-ch audio I/O and 1-ch alarm I/O |
