Camera |
|
Image Sensor |
1/3" Progressive Scan CMOS |
Signal System |
PAL/NTSC |
Min. Illumination |
0.01Lux @ (F1.2, AGC ON) ,0 Lux with IR |
Shutter time |
1/3 s to 1/10,000 s |
Lens |
4mm, 6mm @ F2.0 |
Lens Mount |
M12 |
Adjustment Range |
Pan: -30°-30°, Tilt: 0~75°, Rotation: 0-360° |
Day& Night |
IR cut filter with auto switch |
Wide Dynamic Range |
Digital WDR |
Digital noise reduction |
3D DNR |
Compression Standard |
|
Video Compression |
H.264/MJPEG/H.264+ |
H.264 code profile |
Main Profile |
Video bit rate |
256Kbps~16Mbps |
Dual Stream |
Yes |
Image |
|
Max. Image Resolution |
2560 x 1920 |
Frame Rate |
50Hz: 20fps (2560×1920), 25fps (2048x1536), 25fps(1920×1080), 25fps(1280×720) 60Hz: 20fps (2560×1920), 30fps (2048x1536), 30fps(1920×1080), 30fps(1280×720) |
Main Stream |
50Hz: 20fps (2560×1920), 25fps (2048x1536), 25fps(1920×1080), 25fps(1280×720) 60Hz: 20fps (2560×1920), 30fps (2048x1536), 30fps(1920×1080), 30fps(1280×720) |
Image Settings |
Rotate mode, Saturation, Brightness, Contrast adjustable by client software or web browser |
Network |
|
Network Storage |
NAS (Support NFS,SMB/CIFS), ANR |
Alarm Trigger |
Line Crossing, Intrusion Detection, Motion detection, Dynamic analysis, Tampering alarm, Network disconnect , IP address conflict, Storage exception |
Protocols |
TCP/IP, UDP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, Bonjour |
System Compatibility |
ONVIF (Profile S, Profile G), PSIA, CGI, ISAPI |
Interface |
|
Audio |
1x audio I/O *only for –S models |
Communication Interface |
1 RJ45 10M / 100M Ethernet interface |
Alarm |
1x alarm I/O *only for –S models |
On-board storage |
Built-in Micro SD/SDHC/SDXC slot, up to 128 GB |
Reset Button |
Yes |
General |
|
Operating Conditions |
-30 °C ~ 60 °C (-22 °F ~ 140 °F) Humidity 95% or less (non-condensing) |
Power Supply |
12 VDC ± 10%, PoE (802.3af) |
Power Consumption |
Max. 5W |
Impact Protection |
IK08 Protection Level |
Weather Proof |
IP66 |
IR Range |
10 meters |
Dimensions |
99.3×96.7×52.8 mm (3.9” × 3.8”× 2.1”) |
Weight |
600g (1.32lbs) |
