| Camera |
|
| Image Sensor |
1/2.8" Progressive Scan CMOS |
| Min. Illumination |
0.01Lux @ (F1.2, AGC ON), 0 Lux with IR |
| Shutter time |
1/3 s to 1/10,000 s |
| Lens |
2.8mm, 4mm, 6mm @ F2.0 angle of view: 100°(2.8mm), 90°(4mm), 53.9°(6mm) |
| Lens Mount |
M12 |
| Adjustment Range |
Pan: -30° ~ 30°, Tilt: 0 ~ 75°, Rotation: 0 ~ 360° |
| Day& Night |
IR cut filter with auto switch |
| Wide Dynamic Range |
120 dB |
| Digital noise reduction |
3D DNR |
| Compression Standard |
|
| Video Compression |
H.264/MJPEG/H.264+ |
| H.264 code profile |
Main Profile |
| Video bit rate |
32Kbps~8Mbps |
| Audio Compression |
-S: G.711/G.722.1/G.726/MP2L2 |
| Audio bit rate |
64Kbps(G.711) / 16Kbps(G.722.1) / 16Kbps(G.726) / 32-128Kbps(MP2L2) *only for –S models |
| Dual Stream |
Yes |
| Image |
|
| Max. Image Resolution |
1920 x 1080 |
| Frame Rate |
50Hz: 25fps(1920 × 1080), 25fps (1280 × 960), 25fps (1280 × 720)
60Hz: 30fps(1920 × 1080), 30fps (1280 × 960), 30fps (1280 × 720) |
| Image Settings |
Rotate mode, Saturation, Brightness, Contrast adjustable by client software or web browser |
| BLC |
Yes, zone configurable |
| ROI |
Support |
| Network |
|
| Network Storage |
NAS (Support NFS,SMB/CIFS) |
| Alarm Trigger |
Tampering alarm, Network disconnect, IP address conflict, Storage exception |
| Protocols |
TCP/IP,ICMP,HTTP,HTTPS,FTP,DHCP,DNS,DDNS,RTP,RTSP,RTCP,
PPPoE,NTP,UPnP,SMTP,SNMP,IGMP,802.1X,QoS,IPv6,Bonjour |
| Security |
One-key reset, Anti-Flicker, heartbeat, mirror, password protection, privacy mask, Watermark, IP address filtering |
| System Compatibility |
ONVIF (Profile S, Profile G), PSIA, CGI, ISAPI |
| Interface |
|
| Audio |
1-ch 3.5 mm audio in (Mic in/Line in)/out interface (-S model) |
| Communication Interface |
1 RJ45 10M / 100M Ethernet interface |
| Alarm |
1x alarm I/O *only for –S models
Built-in microphone and 1x audio output *only for –S models |
| On-board storage |
Built-in Micro SD/SDHC/SDXC slot, up to 128 GB |
| Reset Button |
Yes |
| Wi-Fi Specification (-W) |
|
| Wireless Standards |
IEEE802.11b, 802.11g, 802.11n |
| Frequency Range |
2.4 GHz ~ 2.4835 GHz |
| Channel Bandwidth |
20/40MHz Support |
| Modulation Mode |
802.11b: CCK, QPSK, BPSK
802.11g/n: OFDM |
| Security |
64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK, WPS |
Transmit
Output
Power |
11b:17±1.5dBm@11Mbps
11g:14±1.5dBm@54Mbps
11n:12.5±1.5dBm |
Receive
Sensitivity |
11b:-90dBm@11Mbps(Typical)
11g:-75dBm@54Mpbs(Typical)
11n:-74dBm(Typical) |
| Transmission Rate |
11b: 11Mbps
11g: 54Mbps
11n: up to 150Mbps |
| Wireless Range |
50m(depend on environment) |
| Protocols |
802.11b: CCK, QPSK, BPSK, 802.11g/n: OFDM |
| General |
|
| Operating Conditions |
-30 °C ~ 60 °C (-22 °F ~ 140 °F)
Humidity 95% or less (non-condensing) |
| Power Supply |
12 VDC ± 25%, PoE (802.3af Class3) |
| Power Consumption |
Max. 5W |
| Impact Protection |
IK08 Protection Level |
| Weather Proof |
IP67 |
| IR Range |
10 meters |
| Dimensions |
99.3×96.7×52.8 mm |
| Weight |
600 g (1.32 lbs) |
| NOTE |
"-W" series support Wi-Fi (802.11b/g/n) and the modules with Wi-Fi function don’t support the 802.1X protocol. |
