Camera |
|
Image Sensor |
1/2.8" Progressive Scan CMOS |
Min. Illumination |
0.01Lux @ (F1.2, AGC ON) ,0 Lux with IR 0.028Lux @ (F2.0, AGC ON) ,0 Lux with IR |
Shutter time |
1/3 s to 1/100,000 s |
Lens |
4mm @ F2.0, (2.8mm, 6mm optional) Angle of view: 106°(2.8mm), 85°(4mm) , 52°(6mm) |
Lens Mount |
M12 |
Adjustment Range |
Pan:0° - 355°, Tilt: 0° - 75°, Rotation: 0-355° |
Day& Night |
IR cut filter with auto switch |
Wide Dynamic Range |
Digital WDR |
Digital noise reduction |
3D DNR |
Compression Standard |
|
Video Compression |
H.264/MJPEG |
H.264 code profile |
Main Profile |
Video bit rate |
32Kbps~8Mbps |
Dual Stream |
Yes |
Image |
|
Max. Image Resolution |
1920 x 1080 |
Frame Rate |
50Hz: 25fps(1920 × 1080), 25fps (1280 × 960), 25fps (1280 × 720) 60Hz: 30fps(1920 × 1080), 30fps (1280 × 960), 30fps (1280 × 720) |
Image Settings |
Rotate mode, Saturation, Brightness, Contrast adjustable by client software or web browser |
BLC |
Yes, zone configurable |
ROI |
Support |
Network |
|
Network Storage |
Built-in Micro SD/SDHC/SDXC slot, up to 128G, NAS(NFS, SMB/CIFS) |
Alarm Trigger |
Intrusion detection, Defocus detection, Motion detection, Face detection, line crossing detection, Dynamic analysis, Tampering alarm, Network disconnect, IP address conflict, Storage exception |
Protocols |
TCP/IP,ICMP,HTTP,HTTPS,FTP,DHCP,DNS,DDNS,RTP,RTSP,RTCP, PPPoE,NTP,UPnP,SMTP,SNMP,IGMP,802.1X,QoS,IPv6,Bonjour |
Security |
User Authentication, Watermark |
System Compatibility |
ONVIF, PSIA, CGI, ISAPI |
Interface |
|
Communication Interface |
1 RJ45 10M / 100M Ethernet interface |
Alarm Input |
1 |
Alarm Output |
1 |
On-board storage |
Built-in Micro SD/SDHC/SDXC slot, up to 128 GB |
Wi-Fi Specification (-W) |
|
Wireless Standards |
IEEE802.11b, 802.11g, 802.11n |
Frequency Range |
2.4 GHz ~ 2.4835 GHz |
Channel Bandwidth |
20/40MHz Support |
Security |
64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK, WPS |
Transmit Power |
11b: 17±1.5dBm @ 11Mbps 11g: 14±1.5dBm @ 54Mbps 11n: 12.5±1.5dBm |
Receive Sensitivity |
11b: -90dBm @ 11Mbps (Typical) 11g: -75dBm @ 54Mpbs (Typical) 11n: -74dBm (Typical) |
Wireless Range |
50m(depend on environment) |
Protocols |
802.11b: CCK, QPSK, BPSK 802.11g/n: OFDM |
General |
|
Operating Conditions |
-30 °C ~ 60 °C (-22 °F ~ 140 °F) Humidity 95% or less (non-condensing) |
Power Supply |
12 VDC ± 10%, PoE (802.3af) |
Power Consumption |
MAX. 5.3W |
Impact Protection |
IK10 |
Weather Proof |
IP67 |
IR Range |
Up to 30m |
Dimensions |
Φ111 × 82 (4.4” × 3.2”) |
Weight |
500g (1.1 lbs) |
NOTE |
"-W" series support Wi-Fi (802.11b/g/n) and the modules with Wi-Fi function don’t support the 802.1X protocol. |
