| Camera |
|
| Image Sensor |
1/3" Progressive Scan CMOS |
| Min. Illumination |
0.01Lux @ (F1.2, AGC ON), 0 Lux with IR |
| Lens |
4mm (6mm option) @ F2.0 |
| Lens Mount |
M12 |
| Day & Night |
IR cut filter with auto switch |
| Wide Dynamic Range |
Digital WDR |
| Digital noise reduction |
3D DNR |
| Compression Standard |
|
| Video Compression |
H.264+/H.264/MPEG4/MJPEG |
| H.264 code profile |
Main Profile |
| Video bit rate |
256Kbps~16Mbps |
| Dual Stream |
Yes |
| Image |
|
| Max. Image Resolution |
2560×1920 |
| Frame Rate |
50Hz: 20fps (2560×1920), 25fps (2048x1536), 25fps(1920×1080), 25fps(1280×720) 60Hz: 20fps (2560×1920), 30fps (2048x1536), 30fps(1920×1080), 30fps(1280×720) |
| Image Setting |
Saturation, Brightness, Contrast , Hue, Sharpness, AGC, White Balance |
| Network |
|
| Network Storage |
NAS (Support NFS,SMB/CIFS), ANR |
| Alarm Trigger |
Motion detection, Dynamic Analysis, Tampering alarm, Network disconnect, IP address conflict, Storage exception |
| Protocols |
TCP/IP, UDP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, Bonjour |
| System Compatibility |
ONVIF (Profile S, Profile G), PSIA, CGI, ISAPI |
| Interface |
|
| Communication Interface |
1 RJ45 10M / 100M Ethernet interface |
| General |
|
| Operating Conditions |
-30 °C – 60 °C (-22 °F – 140 °F), Humidity 95% or less (non-condensing), -H: -40 °C – 60 °C |
| Power Supply |
12 VDC ± 10%, PoE (802.3af) |
| Power Consumption |
Max. 5.5 W Max. 9W with pan and tilt |
Ingress Protection level |
IP66 |
| IR Range |
Up to 30m |
| Dimensions |
70×154.2×60.5 mm (2.8” × 6.2” × 2.4”) |
| Weight |
500g (1.1 lbs) |
