Camera
|
| Image Sensor |
1/3" Progressive Scan CMOS |
| Effective Pixels |
1280(H)x720(V) |
| Signal System |
PAL/NTSC |
| Minimum Illumination |
Color: 0.05Lux@( F1.4,AGC ON); B/W: 0.01Lux@( F1.4,AGC ON) |
| White Balance |
Auto/Manual/ATW/Indoor/Outdoor |
| AGC |
Auto/Manual |
| BLC |
ON/OFF |
| WDR |
Support |
| Shutter Time |
PAL: 1-1/10,000s
NTSC: 1-1/10,000s |
| Day& Night |
ICR |
| Digital Zoom |
16X |
| Privacy Masking |
8 privacy masks programmable |
| Auto Focus |
Auto / Semi-automatic / Manual |
|
Lens
|
| Focal Length |
4-92mm, 23x |
| Zoom Speed |
Approx.4.0s(Optical Wide-Tele) |
| Angle of View |
49-2.2 degree (Wide-Tele) |
| Aperture Range |
F1.4-F3.5 |
| Minimum Working Distance |
10-1000mm(Wide-Tele) |
|
Pan and Tilt
|
| Range |
360°endless |
| Speed |
Pan Manual Speed: 0.1°~160°/s, Pan Preset Speed: 160°/s |
| Tilt Range |
0°~90° |
| Tilt Speed |
Tilt Manual Speed: 0.1°~120°/s, Tilt Preset Speed: 120°/s |
| Proportional Zoom |
Rotation speed can be adjusted automatically according to zoom multiples |
| Number of Preset |
256 |
| Patrol |
8 patrols, up to 32 presets per patrol |
| Pattern |
4 patterns, with the recording time not less than 10 minutes per pattern |
| Power loss recovery |
Support |
| Park Action |
Preset / Patrol / Pattern / Pan scan / Tilt scan / Random scan / Frame scan / Panorama scan |
| PTZ Position Display |
ON/OFF |
| Freeze Frame |
Support |
|
Alarm
|
| Alarm Input |
2 |
| Alarm Output |
1 |
|
Input & Output
|
| Turbo HD Output |
1 turbo HD1080p output, BNC |
|
General
|
| RS-485 Protocols |
HIKVISION, Pelco-P, Pelco-D, self-adaptive |
| Menu Language |
English/Chinese |
| Power Supply |
24V DC |
| Power Consumption |
Outdoor dome: Max. 18W (Heater On), Max. 12W(Heater Off)
Indoor dome: Max.12W |
| Working Temp/Humidity |
-30°C ~ 65°C (-22°F ~ 149°F)
90% or less |
| Protection Level |
IP66 standard (outdoor dome)
TVS 4,000V lightning protection, surge protection and voltage transient protection |
| Dimensions |
Φ185×330mm (Φ7.28”×12.99”) |
| Weight (approx.) |
2Kg(4.41Ibs) (Outdoor)
2Kg(4.41Ibs) (Indoor/In-ceiling) |
| Mount Option |
Long-arm wall mount: DS-1602ZJ; Corner mount: DS-1602ZJ-corner; Pole Mount: DS-1602ZJ-pole;
Power box mount:DS-1602ZJ-box;Swan-neck mount: DS-1619ZJ |
