Brand: Avtech

GL 302 Pan& Tilt Outdoor + Scanner

Rp 750.000

Harga Lama: Rp 800.000

tidak termasuk pengiriman

Outdoor/Indoor Pan/Tilt
IP can be used for IP Surveillance

Qty:

Overview
Contact Us

Model	GL-302 ; GL-302IP
Type	Outdoor/Indoor Pan/Tilt IP can be used for IP Surveillance
Max. Load	7 kg
Material	Plastic Steel
PAN	355°
TILT	100°
Rotational Speed	6° per second
Dimension	179(L)X115(W)X180(H)mm
Packing	12 pcs in one carton
N.W,G.W, Cu’ft	GL-302: 19 kg, 22 kg 2 cu’ft GL-302IP: 25 kg, 26 kg, 2 cu’ft

Specification

Model No.:	GL-302
Description	IP PTZ Receiver
Feature:	l Built in PELCO D 2400 Protocol. l PAN & TILT control. l Lens control: zoom, focus. l 1 Auxiliary Relay provide for any desired functions: alarm, wash/wipers, lighting l Easy addressed code setting. (00-99). l Allows the pan tilt power AC24V, zoom lens power DC12 (2A-Max.). l Built-in power surge protection. l Support all pan, tilt, zoom lens. l Low Cost, economic type. l Easy wiring. l 33 Molex cable included for wire connection with PTZ devices. (2 pin, 4 pin, 8 pin).
Operating Voltage	AC 24V
Transmission	RS485
Cable	CAT 5 Twisted Pair Cable
Transmission Range	1200 meters
Storage Temperature	-30℃~70℃
Operation Temperature	-10℃~45℃

Namamu *

Email Anda *

Pertanyaan *

Model	GL-302 ; GL-302IP
Type	Outdoor/Indoor Pan/Tilt IP can be used for IP Surveillance
Max. Load	7 kg
Material	Plastic Steel
PAN	355°
TILT	100°
Rotational Speed	6° per second
Dimension	179(L)X115(W)X180(H)mm
Packing	12 pcs in one carton
N.W,G.W, Cu’ft	GL-302: 19 kg, 22 kg 2 cu’ft GL-302IP: 25 kg, 26 kg, 2 cu’ft

Specification

Model No.:	GL-302
Description	IP PTZ Receiver
Feature:	l Built in PELCO D 2400 Protocol. l PAN & TILT control. l Lens control: zoom, focus. l 1 Auxiliary Relay provide for any desired functions: alarm, wash/wipers, lighting l Easy addressed code setting. (00-99). l Allows the pan tilt power AC24V, zoom lens power DC12 (2A-Max.). l Built-in power surge protection. l Support all pan, tilt, zoom lens. l Low Cost, economic type. l Easy wiring. l 33 Molex cable included for wire connection with PTZ devices. (2 pin, 4 pin, 8 pin).
Operating Voltage	AC 24V
Transmission	RS485
Cable	CAT 5 Twisted Pair Cable
Transmission Range	1200 meters
Storage Temperature	-30℃~70℃
Operation Temperature	-10℃~45℃
