Main Processor
|
Embedded processor |
Operating System
|
Embedded LINUX |
Video Input (BNC)
|
24 channel, BNC |
Video Standard HDCVI & IP
|
720P HDCVI Camera & All channels support 1080P/720P IP Camera |
Audio Input
|
16 channel, BNC |
Audio Output
|
1 channel, BNC |
Two-way Talk
|
1 channel Input,1 channel Output, BNC |
Interface
|
2 HDMI, 1 VGA, 1 TV |
Interface
|
1920×1080, 1280×1024, 1280×720, 1024×768 |
Privasi masking
|
4 rectangular zones (each camera) |
OSD Menu
|
Camera title, Time, Video loss, Camera lock, Motion detection, Recording |
Video Compression Format
|
H.264 |
Audio Compression Format
|
G.711 |
Record Rate
|
720P/960H/D1/HD1/2CIF/CIF(1~25/30fps) & CIF/QCIF(1~25/30fps) |
Bit rate
|
48~4096Kb/s |
Record Mode
|
Manual, Schedule(Regular(Continuous), MD), Stop |
Record Interval
|
1~60 min (default: 60 min), Pre-record: 1~30 sec, Post-record: 10~300 sec |
Trigger Events
|
Recording, PTZ, Tour, Alarm out, Video Push, Email, FTP, Snapshot, Buzzer & Screen tips |
Video Detection
|
Motion Detection, MD Zones: 396(22×18), Video Loss & Camera Blank |
Alarm in
|
16 channel |
Relay Output
|
6 channel |
Synchronous playback
|
1/4/8/16 |
Search & Playback (Search)
|
Time/Date, MD & Exact search (accurate to second) |
Search & Playback Functions
|
Play, Pause, Stop, Rewind, Fast play, Slow play, Next file, Previous file, Next camera, Previous camera, Full screen, Repeat, Shuffle, Backup selection, Digital zoom |
Backup Mode
|
USB Device/eSATA Device/Internal SATA burner/Network |
Ethernet
|
2RJ-45 port (10/100M/1000M) |
Network Functions
|
HTTP, IPv4/IPv6, TCP/IP, UPNP, RTSP, UDP, SMTP, NTP, DHCP, DNS, PPPOE, DDNS, FTP, IP Filter, SNMP, P2P |
Max. User Access
|
128 users |
Smart Phone (Platform)
|
iPhone, iPad, Android, Windows Phone |
Internal HDD
|
8 SATA ports(8HDDs or 6HDDs+1CD/DVD-RW), up to 32TB |
External HDD
|
1 eSATA port |
USB interface
|
4 ports (2 Rear), USB2.0 |
RS232
|
1 port, For PC communication & Keyboard |
RS485 Port
|
1 port RS485 for PTZ control, 1 port RS422 for Keyboard |
Power Supply
|
AC 100~240 V, 50/60 Hz |
Power Consumption (±10%)
|
40W(Without HDD) |
Working Temperature/Humidity
|
-10°C ~+55°C/10%~90%RH / 86~106kpa |
Dimensions (mm)
|
2U, 440mm×460mm×89mm |
Weight
|
6.5KG(without HDD) |
