Main Processor
|
Embedded processor |
Operating System
|
Embedded LINUX |
Video Input (BNC)
|
4 channel |
Video Standard HDCVI & IP
|
1080P/720P HDCVI Camera & Support 2ch 1080P/720P/D1/CIF IP Camera |
Audio Input
|
1 channel, RCA |
Audio Output
|
1 channel, RCA |
Two-way Talk
|
Reuse audio input/output channel 1 |
Interface
|
1 HDMI, 1 VGA |
Resolution
|
1920×1080, 1280×1024, 1280×720, 1024×768 |
Display Split
|
1/4 |
Privasi masking
|
4 rectangular zones (each camera) |
OSD Menu
|
Camera title, Time, Video loss, Camera lock, Motion detection, Recording |
Video Compression Format
|
H.264 |
Audio Compression Format
|
G.711 |
Recording Resolution
|
1080P(1920×1080)/720P(1280×720)/960H(960×576/960×480)/D1/4CIF(704×576/704×480) / CIF(352×288/352×240) / QCIF(176×144/176×120) |
Record Rate
|
1080P(1~12/15fps)/720P/960H/D1/HD1/2CIF/CIF(1~25/30fps); CIF/QCIF(1~25/30fps), D1(1~12/15fps) |
Bit rate
|
48~4096Kb/s |
Record Mode
|
Manual, Schedule(Regular(Continuous), MD), Stop |
Record Interval
|
1~60 min (default: 60 min), Pre-record: 1~30 sec, Post-record: 10~300 sec |
Trigger Events
|
Recording, PTZ, Tour, Video Push, Email, FTP, Spot, Snapshot, Buzzer & Screen tips |
Video Detection
|
Motion Detection, MD Zones: 396(22×18), Video Loss & Camera Blank |
Synchronous playback
|
1/4 |
Search & Playback (Search)
|
Time/Date, MD & Exact search (accurate to second) |
Search & Playback Functions
|
Time/Date, MD & Exact search (accurate to second) |
Backup Mode
|
USB Device/Network/Internal SATA burner |
Ethernet
|
RJ-45 port (10/100M) |
Network Functions
|
HTTP, IPv4/IPv6, TCP/IP, UPNP, RTSP, UDP, SMTP, NTP, DHCP, DNS, PPPOE, DDNS, FTP, IP Filter, SNMP, P2P |
Max. User Access
|
128 users |
Smart Phone (Platform)
|
iPhone, iPad, Android, Windows Phone |
Internal HDD
|
1 SATA port, up to 4TB |
USB interface
|
2 ports(1 Rear), USB2.0 |
RS485 Port
|
1 port, For PTZ Control |
Power Supply
|
DC12V/2A |
Power Consumption (±10%)
|
10W(without HDD) |
Working Temperature/Humidity
|
-10°C ~+55°C / 10%~90%RH / 86~106kpa |
Dimensions (mm)
|
Mini 1U, 325mm×255mm×55mm |
Weight
|
1.5KG(without HDD) |
