Brand: CP Plus

CP Plus CP-UNC-DP20L2C

Rp 6.000.000

tidak termasuk pengiriman

1/3” 2 Megapixel PS CMOS image sensor
H.264 & MJPEG dual-stream encoding
25/30fps@1080P(1920×1080)
DWDR, Day/Night(ICR), 2DNR, AWB, AGC, BLC
Max. IR distance: 20m
3.6mm Lens(6mm optional)
Support PoE, IP66
Mobile Software: CMOB
CMS Software: IPSS

Qty:

Overview
Contact Us

Specifications
Image Sensor	1/3” 2Megapixel CMOS
Minimum Illumination	Color: 0. 1Lux/F1.2, B/W: 0.01Lux/F1.2; 0Lux/F1.2(IR on)
Shutter Speed	Auto/Manual, 1/3~1/10000s
White Balance	Auto
AGC control	Auto/Manual
Lens	3.6mm (6mm optional)
S/N Ratio	more than 50 dB
Video Compression	H.264/MJPEG
Resolution	1080P(1920×1080) / 720P(1280×720) / D1(704×576) / CIF(352×288)
Video Streaming	Main Stream 1080P/720P(1 ~ 25/30fps), Sub Stream D1/CIF(1 ~ 25/30fps)
Privacy Masking	Up to 4 areas
ICR	Auto(ICR) / Color / B/W
Smart Phone	iPhone, iPad, Android, Windows Phone
User Account	10 users
Interface	RJ-45 (10/100Base-T)
Protocol	IPv4/IPv6, HTTP, HTTPS, SSL, TCP/IP, UDP, UPnP, ICMP, IGMP, SNMP, RTSP, RTP, SMTP, NTP, DHCP, DNS, PPPOE, DDNS, FTP, IP Filter, QoS, Bonjour, ONVIF Ver. 2.0
IR	Max. IR Distance: 20m
Operating Temperature	-10°C~+60°C, 10%~90%
Power Source	DC12V, PoE
Power Consumption	Max.5W
Weatherproof Standard	IP66
Dimension	φ113mm×86mm
Weight	400g
Back Light Comp.	BLC / HLC / DWDR

Namamu *

Email Anda *

Pertanyaan *

Specifications
Image Sensor	1/3” 2Megapixel CMOS
Minimum Illumination	Color: 0. 1Lux/F1.2, B/W: 0.01Lux/F1.2; 0Lux/F1.2(IR on)
Shutter Speed	Auto/Manual, 1/3~1/10000s
White Balance	Auto
AGC control	Auto/Manual
Lens	3.6mm (6mm optional)
S/N Ratio	more than 50 dB
Video Compression	H.264/MJPEG
Resolution	1080P(1920×1080) / 720P(1280×720) / D1(704×576) / CIF(352×288)
Video Streaming	Main Stream 1080P/720P(1 ~ 25/30fps), Sub Stream D1/CIF(1 ~ 25/30fps)
Privacy Masking	Up to 4 areas
ICR	Auto(ICR) / Color / B/W
Smart Phone	iPhone, iPad, Android, Windows Phone
User Account	10 users
Interface	RJ-45 (10/100Base-T)
Protocol	IPv4/IPv6, HTTP, HTTPS, SSL, TCP/IP, UDP, UPnP, ICMP, IGMP, SNMP, RTSP, RTP, SMTP, NTP, DHCP, DNS, PPPOE, DDNS, FTP, IP Filter, QoS, Bonjour, ONVIF Ver. 2.0
IR	Max. IR Distance: 20m
Operating Temperature	-10°C~+60°C, 10%~90%
Power Source	DC12V, PoE
Power Consumption	Max.5W
Weatherproof Standard	IP66
Dimension	φ113mm×86mm
Weight	400g
Back Light Comp.	BLC / HLC / DWDR
